Schneider Electric NSYZZ254G Polyester glassreinf. plinth for encl. PLAZ(T)54 front opening IP44-IK10 RAL7035
- MPN: NSYZZ254G
- PPN: SCH-NSYZZ254G
CAD
$592.89
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Plinth to be used with PanelSeT PLA and PanelSeT PHD enclosures. The plinth is to be used in multi-purpose applications. The width is 535mm. The height is 200mm. The depth is 410mm. The kit is made of fixing elements, 2 front panels and 2 side parts. The product is made of grey Material : Plastic. (RAL 7035). (RAL 7035). Mechanical protection rating is IK10.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Spain
- Width
- 21.06 in
Height7.87 in
Depth410 mm
Physical Attributes
- Color
- plinth Gray RAL 7035)
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Device Composition
- fixing elements2 front panel, 2 side part
- Local Data Status
- Publishable
- Return Indicator
- N
- Stock Policy
- 2
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- China Rohs Label
- 7
- Without Single Use Plastic
- No
- Tier Id
- 2
- Function Option Id
- STANDARD
- Product Kit Identifier
- N
- Energy Efficiency Optimized
- False
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range
- PanelSeT
- Sustainable Packaging
- No
- Height Nominal
- 200 mm
- Width Nominal
- 535 mm
- Accessory / Separate Part Category
- enclosure accessory
- Package Weight(Lbs)
- 6.706 kg
- Warranty (In Months)
- 18
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Enclosure Nominal Dimensions- D: 420 mm, - D: 420 mm, - D: 420 mm, - D: 420 mm
Local Publishable Date2026-04-13
Stocking FlagY
Weee ScopeOut
Eoli Availability DisplayNo need of specific recycling operations
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeNo
Rohs Eur Conformity Date1916
China Rohs In ScopeYes
With Recycled CardboardNo
Product Contributes To Saved And Avoided EmissionsNo
Tier2
Function OptionStandard
Device Applicationmulti-purpose
Fixing Modeby screws - on side parts
Product Or Component Typeplinth
ReturnabilityNo
Pep CodeENVPEP1109021EN
Height Useful200 mm
Width Real535 mm
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code3926909989
Environment Attributes Main
- Take Back
- No
- China Rohs Regulation
- X
- Environmental Disclosure
- ENVPEP1109021EN
- Ip Degree Of Protection
- IP44
- Packaging Without Single Use Plastic
- No
- Pep Code
- ENVPEP1109021EN
Recycled Metal Content At Cr Level0 %
Mercury FreeYes
Eu Rohs DirectiveCompliant By Exemption
Packaging Made With Recycled CardboardNo
Reach RegulationReference contains Substances of Very High Concern above the threshold
General Attributes
- Product Or Component Type
- plinth
ETIM
- ETIM 8
- EC000721
ETIM 9EC000721
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
