Balluff BML-S1G0-B7ED-M5EA-D0-S284 Absolute Rotary Magnetic Encoder, 48 m Range, 1 µm Resolution, Die-Cast Zinc
- MPN: BML-S1G0-B7ED-M5EA-D0-S284
- PPN: BAL-BML04PE
CAD
$2347.44
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Balluff's absolute linear BML magnetic encoders provide for absolute position feedback in any position – ready to use and without a reference run. Our encoders also work with high accuracy on large diameters, are extremely compact and easy to integrate into motors.
Documentation & Downloads
Specifications
Additional
- Resolution
- 1 µm
- Read Distance
- 0.01-0.8 mm
- Interface
- BiSS-C; Analog sin/cos (1 Vpp)
- Connection
- M12x1-Male, 12-pin connector
- Ambient Temperature
- -20 to 70 °C
Measuring Range48 m
Operating Voltage4.75-5.25 VDC / 10-28 VDC
Dimension16 x 18.5 x 80.3 mm
Housing MaterialDie-cast zinc, nickel plated, chrome-plated
Approval/ConformitycURus, CE, EAC, WEEE
