Weidmuller 2495080000 maxGUARD AMG XMD EX, 0.24 Inch Width, 4.921 Inch Height, 12 A Current Load

  • MPN: 2495080000
  • PPN: WDM-2495080000

CAD

$8.99

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

Potential distributor

Documentation & Downloads

Specifications

General Data

Conformal coatingYes
Protection degreeIP20
Current load per contact point12 A
Total current load per potential24 A

Probability Of Failure

MTTF50,000 Years

Approvals

ApprovalsABS, BURVER, CE, CULUS, CULUSEX, DEMKOATEX, DNV GL, EAC, IECEXULD, LLOYDSREG, RINA, TUEV
UL File Number SearchE258476
ROHSConform

Dimensions And Weights

Width6.1 mm
Height125 mm
Depth96.5 mm
Net weight27.5 g
Width (inches)0.24 inch
Height (inches)4.921 inch
Depth (inches)3.799 inch

Classifications

ETIM 6.0EC000897
eClass 9.027-14-11-20
eClass 10.027-14-11-20
ETIM 7.0EC000897
eClass 9.127-14-11-20

Output

Connection systemPUSH IN

Environmental Product Compliance

REACH SVHCLead 7439-92-1

Connection Data (Output)

Conductor cross-section, AWG/kcmil , max.12
Conductor cross-section, flexible , max.2.5 mm²
Conductor cross-section, rigid , max.2.5 mm²
Connection systemPUSH IN
Screwdriver blade0.6 x 3.5
Conductor cross-section, AWG/kcmil , min.26
Conductor cross-section, flexible , min.0.14 mm²
Conductor cross-section, rigid , min.0.14 mm²
Number of terminals4 (4x GND), 2 x 1.5 mm², 2 x 2.5 mm²

Ratings Iecex/Atex/Cul

Certificate No. (ATEX)DEMKO17ATEX1870X
Certificate no. (cULus)E258476
Certificate No. (IECEX)IECEXULD17.0018X
maxGUARD AMG XMD EX, 0.24 Inch Width, 4.921 Inch Height, 12 A Current Load
maxGUARD AMG XMD EX, 0.24 Inch Width, 4.921 Inch Height, 12 A Current Load
