APC BK500BLK Back-UPS 500VA Tower, 120V, 6 NEMA 5-15R Outlets, Lead-Acid Battery, 13.82 lb
- MPN: BK500BLK
- UPC: 731304021360
- PPN: APC-BK500BLK
CAD
$282.09
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Back-UPS 500VA Tower, 120V, 6 NEMA 5-15R Outlets, Lead-Acid Battery, 13.82 lb
Features
- Serial connection — Use your PC to access additional power protection and management features for your UPS via a serial port.
- USB connection — Use your PC to access additional power protection and management features for your UPS via a USB Port.
- Simple battery replacement — Increases UPS availability by allowing quick, easy battery replacement.
- Disconnected battery notification — Warns when a battery is not available to provide backup power.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Dataline surge protection — Provides protection of connected equipment from power surges on the data lines.
- Hot-swappable batteries — Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Lifetime data recovery warranty — Provides peace of mind by providing professional data recovery services in the event data is lost due to the failure of the unit.
- Transformer-block spaced outlets — Protect equipment with input transformer blocks without blocking access to other receptacles.
- Building Wiring Fault Indicator — This LED informs users of potentially dangerous wiring problems in the wall circuit.
Documentation & Downloads
Specifications
Additional
- Output Power Capacity
- 500 VA, 300 W
- Nominal Output Voltage
- 120 V
- Output Connections
- 3 NEMA 5-15R, 3 NEMA 5-15R surge
- Battery Power
- 78 VAh
- Topology
- Standby
- Surge Energy Rating
- 480 J
- Storage Temperature Range
- 5–113 °F (-15–45 °C)
- Storage Relative Humidity
- 0–95 %
- Storage Altitude
- 0–50,000 ft
- Heat Dissipation
- 24 Btu/h
- Height
- 6.50 in (165 mm)
- Depth
- 11.18 in (284 mm)
- Mounting Location
- Front
- Mercury Free
- Yes
- Warranty
- 36 months
- Country of Origin
- India
Input Voltage120 V
Input Connection TypeNEMA 5-15P
Battery TypeLead-Acid battery
Typical Recharge Time8 h
Waveform TypeStepped approximation to a sinewave
Operating Temperature Range32–104 °F (0–40 °C)
Operating Relative Humidity0–95 %
Operating Altitude0–10,000 ft
Acoustic Level45 dBA
Cord Length6 ft (1.83 m)
Width3.58 in (91 mm)
Weight13.82 lb (6.27 kg)
CompliancecUL Listed, ENERGY STAR V2.0 (USA), California (CEC) Battery Charger, Industry Canada, RoHS Compliant
ColorBlack
Replacement BatteryRBC2
