APC BR650MI Back-UPS Pro 650VA, Tower, 6x IEC C13, AVR, LCD Display, User Replaceable Battery
- MPN: BR650MI
- UPC: 731304346937
- PPN: APC-BR650MI
CAD
$362.69
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Back-UPS Pro 650VA, Tower, 6x IEC C13, AVR, LCD Display, User Replaceable Battery
Features
- Audible alarms — Provides notification of changing utility power and UPS power conditions
- Automatic self-test — Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Automatic Voltage Regulation (AVR) — Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
- Battery failure notification — Provides early-warning fault analysis on batteries enabling timely preventive maintenance
- Battery replacement without tools — Enables fast battery replacement, lowering Mean Time to Repair (MTTR).
- Battery-protected and surge-only outlets — Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
- Boost and Trim Automatic Voltage Regulation (AVR) — Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Dataline surge protection — Provides protection of connected equipment from power surges on the data lines.
- Disconnected battery notification — Warns when a battery is not available to provide backup power.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- Hot-swappable batteries — Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- LCD graphics display — Text and mimic diagrams that display modes of operation, system parameters and alarms.
- Safety-agency approved — The UPS is UL1778 Listed
- USB connectivity — Provides management of the UPS via a USB port (not available on all models).
- User-replaceable batteries — Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Documentation & Downloads
Specifications
Additional
- Output Power Capacity
- 650 VA / 390 W
- Output Frequency
- 50/60 Hz ± 3 Hz (utility), 50/60 Hz ± 1 Hz (battery)
- Waveform Type
- Stepped approximation to a sinewave
- Output Connections
- 6 IEC outlets with battery backup and surge protection
- Input Cord Length
- 6 ft
- Unit Weight
- 6.4 kg
- Battery Replacement
- User replaceable, hot-swappable, tool-free
- Runtime Half Load
- 10.5 mins
- Dataline Surge Protection
- 1 Gb network protection
- Approvals
- A-Tick, C-Tick, CE, EAC, GS Mark, RCM, TISI, UL Listed, TUV GS, CB 60950 & 62040, Taiwan EMC lab: TelePermit
- Warranty
- 3 years repair or replace (EU), 2 years repair or replace (others), includes lifetime Equipment Protection Policy up to €150,000
Output Voltage196 to 264 V AC (utility), 230 V ± 8% (battery)
Maximum Input Current10.0 A
TopologyLine interactive
Interface Port(s)USB
Dimensions (HxWxD)19.0 cm x 9.1 cm x 31.0 cm (7.48 in x 3.58 in x 12.2 in)
Battery TypeLead-acid battery
Runtime Full Load3 mins
Surge Energy Rating557 J
Overload Protection10A circuit breaker (line), internal current limit (battery)
RoHS ComplianceCompliant
Product OrientationTower
