APC SUA5000RMT5U Smart-UPS 5000VA 208V Rackmount/Tower, 5U, Black, Lead-Acid Battery, 215.46 lb
- MPN: SUA5000RMT5U
- UPC: 731304255338
- PPN: APC-SUA5000RMT5U
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Smart-UPS 5000VA 208V Rackmount/Tower, 5U, Black, Lead-Acid Battery, 215.46 lb
Features
- Resettable circuit breakers — Enables a quick recovery from overload events.
- Provides proactive notifications of changing power or unit conditions and provides the user the ability to remotely control PMU functions. — Provides proactive notifications of changing power or unit conditions and provides the user the ability to remotely control PMU functions.
- Boost and Trim Automatic Voltage Regulation (AVR) — Gives higher application availability by correcting low and high voltage conditions without using the battery (not available on all models).
- Serial connectivity — Provides management of the UPS via a serial port.
- Disconnected battery notification — Warns when a battery is not available to provide backup power.
- Adjustable voltage sensitivity — Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
- Adjustable voltage-transfer points — Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
- Audible alarms — Provides notification of changing utility power and UPS power conditions
- Automatic self-test — Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Hot-swappable batteries — Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
- Network manageable — Provides remote power management of the UPS over the network.
- Rack/Tower convertible — Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
- Safety-agency approved — Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
- SmartSlot — Customize UPS capabilities with management cards.
- Temperature-compensated battery charging — Prolongs battery life by regulating the charge voltage according to battery temperature.
- Intelligent battery management — Maximizes battery performance, life, and reliability through intelligent, precision charging.
Documentation & Downloads
Specifications
Additional
- Power Capacity
- 5000 VA
- Input Voltage
- 208 V
- Output Voltage
- 208 V
- Output Connections
- 2 NEMA L6-20R, 2 NEMA L6-30R
- Waveform Type
- Sine Wave
- Typical Recharge Time
- 3 h
- Weight
- 215.46 lb (97.73 kg)
- Width
- 19.02 in (483 mm)
- Rack Unit Size
- 5U
- Mount Position
- front
- Country of Origin
- Philippines
- Replacement Battery
- RBC55
Output Power Capacity5000 VA
Nominal Output Voltage208 V
Input Connection TypeNEMA L6-30P
TopologyLine Interactive
Surge Energy Rating480 J
Battery TypeLead-Acid battery
Height8.74 in (222 mm)
Depth25.98 in (660 mm)
Cable Length8 ft (2.44 m)
ColorBlack
ComplianceCSA Certified, RoHS Compliant with Exemptions, Prop 65 Compliant
