APC SUA5000RMT5U Smart-UPS 5000VA 208V Rackmount/Tower, 5U, Black, Lead-Acid Battery, 215.46 lb

  • MPN: SUA5000RMT5U
  • UPC: 731304255338
  • PPN: APC-SUA5000RMT5U
Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Description

The APC Smart-UPS is a rackmount or tower UPS with a power rating of 5000VA and 4000 watts. It supports 208V input and output, and includes multiple output connections such as 2 NEMA L6-20R and 2 NEMA L6-30R. The UPS uses lead-acid batteries and features a SmartSlot for additional management options.

Features

  • Enables a quick recovery from overload events.
  • Provides proactive notifications of changing power or unit conditions and provides the user the ability to remotely control PMU functions.
  • Eliminates voltage fluctuations as a source of AV signal degradation and component power-supply stress.
  • Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks.
  • Warns when a battery is not available to provide backup power.
  • Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
  • Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
  • Provides notification of changing utility power and UPS power conditions
  • Periodic battery self-test ensures early detection of a battery that needs to be replaced.
  • Provides temporary battery power when the utility power is out.
  • Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
  • Provides remote power management of the UPS over the network.
  • Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
  • Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
  • Provides management of the UPS via a serial port.
  • Customize UPS capabilities with management cards.
  • Prolongs battery life by regulating the charge voltage according to battery temperature.
  • Gives higher application availability by correcting low and high voltage conditions without using the battery not available on all models.
  • Maximizes battery performance, life, and reliability through intelligent, precision charging.
  • "Intelligent and efficient network power protection from entry level to scalable runtime. "
  • "Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices."
  • "Provides remote management of the UPS over the network."
  • "LED status indicators Quickly understand unit and power status with visual indicators"

Documentation & Downloads

Specifications

Additional

Power Capacity5000 VA
Input Voltage208 V
Output Voltage208 V
Output Connections2 NEMA L6-20R, 2 NEMA L6-30R
Waveform TypeSine Wave
Typical Recharge Time3 h
Weight215.46 lb (97.73 kg)
Width19.02 in (483 mm)
Rack Unit Size5U
Mount Positionfront
Country of OriginPhilippines
Replacement BatteryRBC55
Output Power Capacity5000 VA
Nominal Output Voltage208 V
Input Connection TypeNEMA L6-30P
TopologyLine Interactive
Surge Energy Rating480 J
Battery TypeLead-Acid battery
Height8.74 in (222 mm)
Depth25.98 in (660 mm)
Cable Length8 ft (2.44 m)
ColorBlack
ComplianceCSA Certified, RoHS Compliant with Exemptions, Prop 65 Compliant
