Schneider Electric MG24427 Multi9 - C60 UL1077 - MCB - 1P - 3 A - C Curve - 277 V - 5 kA
Schneider Electric MG24427 Multi9 - C60 UL1077 - MCB - 1P - 3 A - C Curve - 277 V - 5 kA
- MPN: MG24427
- UPC: 785901346166
- PPN: SCH-MG24427
- UNSPSC: 39121603
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$35.15/ EA
Description
Multi9 - C60 UL1077 - MCB - 1P - 3 A - C Curve - 277 V - 5 kA
Specifications
Physical Attributes
- Color
- Gray
Wire Stripping Length14 mm for top or bottom connection
Conformance Attributes
- Product Certifications
- UR, CSA, CCC, IEC
StandardsGB 14048.2, EN/IEC 60947-2, UL 1077, CSA C22.2 No 235
Complementary Attributes
- Line Rated Current
- 3 A 25 °C
Important Information Attributes
- Magnetic Tripping Limit
- 8.5 x In +/- 20 % AC, 12 x In +/- 20 % DC
- Ue Rated Operational Voltage2
- 240 V, 60 V, 415 V
- Local Data Status
- Publishable
- Device Type
- LV equipment - Low voltage circuit breaker
- Traceability
- No
- Average Life Duration
- 15 year(s)
- Scope Perimeter
- At least in Europe
- Reach Full Compliance Status Id
- CONTAINS_SVHC
- ROHS EUR In Scope
- Yes
- ROHS EUR Full Compliance Status
- Compliant with Exemptions
- China ROHS In Scope
- No
- Return Indicator
- N
- H And D Domain
- Safety
- H And D Enrichment Assignment
- no
- H And D Enrichment Class 3
- Circuit Breakers
- Connection Pitch
- 18 mm between devices
- Control Type
- toggle
- Device Application
- distribution
- Electrical Durability
- 10000 cycles
- Local Signalling
- ON/OFF indication
- Mounting Mode
- clip-on
- Network Frequency
- 50/60 Hz
- Package Weight Lbs
- 117.934 g
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Provision For Padlocking
- padlockable
- Returnability
- No
- Sustainable Packaging
- No
- Trip Unit Technology
- thermal-magnetic
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Uimp Rated Impulse Withstand Voltage2
- 6 kVEN/IEC 60947-2
- Medium Desc
- Multi9 - C60 UL1077 - MCB - 1P - 3 A - C Curve - 277 V - 5 kA
- Product Kit Identifier
- N
- Limitation Class
- 3 EN/IEC 60947-2
- Product Name
- Multi9 C60
- Ui Rated Insulation Voltage5
- 500 V AC EN/IEC 60947-2
Network TypeDC, AC
Ue Rated Operational Voltage5240 V, 60 V, 415 V
Local Publishable Date2025-11-13
ServiceabilityNo
Field Service DivisionPPIBS
Legacy WEEE ScopeIn
Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
ROHS EUR StatusCompliant with Exemptions
ROHS EUR Full Compliance Status IdCOMPLIANT_WITH_EXEMPTIONS
With Recycled CardboardYes
H And D HubSESA129878 - LOKANATHLAL, Raghavendra
H And D SubrangeMulti9 OEM MCB
H And D Enrichment FunctionFUSE
H And Dod PlatformMonitoring, Control, Auxiliaries, AFDD, SPD, Fuse, Active
Contact Position Indicatoryes
Curve CodeC
Device Short NameC60 UL1077
Halogen Free StatusHalogen free product
Mechanical Durability20000 cycles
Mounting SupportDIN rail
Overvoltage CategoryIV
Poles Description1P
Product Or Component Typeminiature circuit-breaker
RangeMulti9
Suitability For Isolationyes EN/IEC 60947-2
Tightening Torque2.5-2.5 N.m top or bottom
Tropicalisation2 IEC 60068-1
Ui Rated Insulation Voltage2500 V AC EN/IEC 60947-2
Connections Terminalstunnel type terminal top or bottom) 2.5-25 mm² AWG 14...AWG 4) - rigid
Stocking FlagY
Pep CodeENVPEP1304004
Global Commercial StatusEnd of commercialisation
Connections Terminals3tunnel type terminal top or bottom) 2.5-25 mm² AWG 14...AWG 4) - rigid
Uimp Rated Impulse Withstand Voltage56 kVEN/IEC 60947-2
Environment Attributes Main
- China ROHS Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- EU ROHS Directive
- Compliant By Exemption , Compliant with Exemptions
- ROHS Exemption Information
- Yes
- Halogene Performance
- Halogen free product
- Mercury Free
- Yes
- Ambient Air Temperature For Storage
- -40-80 °C
- Halogen Content Performance
- Halogen free product
- Packaging Made With Recycled Cardboard
- Yes
- Relative Humidity
- 95-95 % 55-55 °C
Ambient Air Temperature For Operation-30-70 °C, -30-70 °C
IP Degree Of ProtectionIP20 conforming to IEC 60529, IP40 (modular enclosure) conforming to IEC 60529
Take BackNo
Recycled Metal Content At Cr Level0 %
9 MM Pitches2
Environmental DisclosureENVPEP1304004
Operating Altitude6561.68 ft (2000 m)
Reach RegulationReference contains Substances of Very High Concern above the threshold
Pep CodeENVPEP1304004
General Attributes
- Product Or Component Type
- miniature circuit-breaker
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
Specifications
- Depth
- 73 mm
