Schneider Electric MG24520 Multi9 - C60 UL1077 - MCB - 2P - 6 A - D Curve - 480Y/277 V - 5 kA
- MPN: MG24520
- UPC: 785901881186
- PPN: SCH-MG24520
CAD
$58.20
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Multi9 - C60 UL1077 - MCB - 2P - 6 A - D Curve - 480Y/277 V - 5 kA
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- France, United States
Depth73 mm
Physical Attributes
- Color
- Gray
Wire Stripping Length14 mm for top or bottom connection
Complementary Attributes
- Line Rated Current
- 6 A 25 °C
Important Information Attributes
- Network Type
- DC, AC
- [Ue] Rated Operational Voltage
- 240 V, 415 V, 440 V, 125 V
- Local Publishable Date
- 2025-11-13
- Stocking Flag
- Y
- Device Type
- LV equipment - Low voltage circuit breaker
- Traceability
- No
- Average Life Duration
- 15 year(s)
- Weee Product Category
- 5
- Rohs Eur In Scope
- Yes
- Rohs Eur Conformity Date
- 1906
- China Rohs In Scope
- No
- Connection Pitch
- 18 mm between phases
- Control Type
- toggle
- Device Application
- distribution
- Electrical Durability
- 10000 cycles
- Local Signalling
- ON/OFF indication
- Mechanical Durability
- 20000 cycles
- Mounting Support
- DIN rail
- Number Of Poles
- 2P
- Overvoltage Category
- IV
- Product Name
- Multi9 C60
- Provision For Padlocking
- padlockable
- Returnability
- No
- Sustainable Packaging
- No
- Trip Unit Technology
- thermal-magnetic
- Weee Label
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Height Nominal
- 81 mm
- [Ui] Rated Insulation Voltage
- 500 V AC EN/IEC 60947-2
- Connections - Terminals
- tunnel type terminal top or bottom) 2.5-25 mm² AWG 14...AWG 4) - rigid
- Nbr. Of Units In Pkg.
- 1
- Warranty (In Months)
- 18
Certificate AgencyUR, CSA, CCC, IEC
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
ServiceabilityNo
Field Service DivisionPPIBS
Weee ScopeIn
Scope PerimeterAt least in Europe
Rohs Eur StatusCompliant
Rohs Eur Full Compliance StatusCompliant
Product Kit IdentifierN
Contact Position Indicatoryes
Curve CodeD
Device Short NameC60 UL1077
Limitation Class3 EN/IEC 60947-2
Magnetic Tripping Limit12 x In +/- 20 % AC17 x In +/- 20 % DC
Mounting Modeclip-on
Network Frequency50/60 Hz
Number Of Protected Poles2
Product AvailabilityNon-Stock - Not normally stocked in distribution facility
Product Or Component Typeminiature circuit-breaker
RangeMulti9
Suitability For Isolationyes EN/IEC 60947-2
Tightening Torque2.5-2.5 N.m top or bottom
Tropicalisation2 IEC 60068-1
Pep CodeENVPEP1304004
Width Nominal36 mm
[Uimp] Rated Impulse Withstand Voltage6 kVEN/IEC 60947-2
Halogen-free StatusHalogen free product
Package Weight(Lbs)231.332 g
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Halogene Performance
- Halogen free product
- 9 Mm Pitches
- 4
- Environmental Disclosure
- ENVPEP1304004
- Halogen Content Performance
- Halogen free product
- Operating Altitude
- 6561.68 ft (2000 m)
- Pep Code
- ENVPEP1304004
Ambient Air Temperature For Storage-40-80 °C, -40-80 °C
Mercury FreeYes
Ambient Air Temperature For Operation-30-70 °C-30-70 °C
Eu Rohs DirectiveCompliant
Ip Degree Of ProtectionIP20 conforming to IEC 60529IP40 (modular enclosure) conforming to IEC 60529
Relative Humidity95-95 % 55-55 °C
General Attributes
- Product Or Component Type
- miniature circuit-breaker
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
