Schneider Electric LC2K09004E7 TeSys K Changeover Contactor 4P, 20A Rated Operational Current, 48V AC
- MPN: LC2K09004E7
- PPN: SCH-LC2K09004E7
CAD
$207.65
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Engineered for reliability and precision, the Schneider Electric TeSys K Changeover Contactor is a versatile solution within the automation and control sector. With a rated operational current of 20A and designed for 4-pole applications, this contractor operates effectively at 48V AC, making it ideal for various industrial settings. Its robust design ensures dependable performance, making it a practical choice for those looking to enhance their control systems with a proven miniature contactor solution. This product is an essential component for those who demand efficiency and quality in their electrical installations.
Documentation & Downloads
Specifications
Additional
- Rated Operational Current
- 20 A (at <60 °C) at <= 440 V AC AC-1
- Rated Making Capacity
- 110 A AC IEC 60947
- Control Circuit Voltage
- 48 V AC 50/60 Hz
- Rated Insulation Voltage
- 600 V UL 508, 690 V IEC 60947-4-1, 600 V CSA C22.2 No 14
- Conventional Free Air Thermal Current
- 20 A (at 60 °C) power circuit
- Overvoltage Category
- III
- Mechanical Durability
- 5 Mcycles
- Maximum Operating Rate
- 3600 cycles/hour
- Hold-in Power Consumption
- 4.5 VA at 20 °C
- Operating Time
- 10 to 20 ms coil energisation and de-energisation, NO opening/closing
- Mounting
- Support plate, rail
- Terminal Wire Size Range
- 1.5 to 4 mm² solid; 0.34 to 2.5 mm² flexible with cable end; 0.75 to 4 mm² flexible without cable end
- Height
- 58 mm (2.28 in)
- Depth
- 57 mm (2.24 in)
- IP Degree of Protection
- IP20
- Ambient Air Temperature for Storage
- -50 to 80 °C (-58 to 176 °F)
- Material
- Pole contacts: 4 NO (Normally Open)
- Product Certifications
- CB, CCC, UL, CSA, EAC, CE, UKCA
- RoHS Compliance
- Compliant (EU, China)
Rated Breaking Capacity110 A at 220...440 V, 80 A at 500 V, 70 A at 660...690 V IEC 60947
Rated Short-Time Withstand Current90 A (1 s), 85 A (5 s), 80 A (10 s), 60 A (30 s), 45 A (1 min), 40 A (3 min), 20 A (≥ 15 min) at 50 °C
Rated Operational Voltage690 V AC 50/60 Hz
Average Impedance3 mOhm at Ith 20 A 50 Hz power circuit
Poles4P
Safety Reliability LevelB10d = 1,369,863 cycles nominal load, 20,000,000 cycles mechanical load
Electrical Durability0.16 Mcycles at 20 A AC-1 ≤ 690 V
Inrush Power30 VA at 20 °C
Heat Dissipation1.3 W
Interlocking TypeMechanical
Terminal TypeScrew clamp
Tightening Torque0.8 to 1.3 N·m
Width90 mm (3.54 in)
Net Weight0.38 kg (0.84 lb)
Ambient Air Temperature for Operation-25 to 50 °C (-13 to 122 °F)
Operating Altitude2000 m (6561.68 ft) without derating
Flame RetardanceV1 UL 94
StandardsEN/IEC 60947-4-1, GB/T 14048.4, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1
Country of OriginFrance
