Hammond Power Solutions C2G0100SP Open Style Control Transformer 100VA 208x416V→120x240V 50/60Hz
- MPN: C2G0100SP
- UPC: 803423214821
- PPN: HPS-C2G0100SP
CAD
$73.78
/ EA
Available to Order from Manufacturer
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
HPS open-style single-phase control transformer rated 100 VA. Primary voltage 208x416, 199x398, 190x380 V; secondary voltage 120x240, 115x230, 110x220 V; 50/60 Hz. Output current 0.83/0.42 A. Approximate shipping weight 2.7 lb.
Features
- Open-style single-phase industrial control transformer
Documentation & Downloads
Specifications
Physical
| Mounting Centers | 2.52 x 2.60 in |
|---|---|
| Height with Fuse Block | 4.43 in |
| Depth | 3.86 in (98 mm) |
| Shipping Weight | 2.7 lb (1.2 kg) |
| Mounting Slot | 0.22 x 0.44 in |
|---|---|
| Width | 3 in (76 mm) |
| Height | 3.13 in (79 mm) |
Electrical
| VA Rating | 100 |
|---|---|
| Secondary Voltage | 120x240, 115x230, 110x220 |
| Output Current | 0.83/0.42 A |
| Primary Voltage | 208x416, 199x398, 190x380 |
|---|---|
| Frequency | 50/60 Hz |
| Phases | 1 |
Identification
| Style | Open |
|---|
Construction
| Mounting Figure | 4 |
|---|---|
| Winding Material | Copper |
| Optional Primary Fuse Kit | PFBK8 |
|---|
