Schneider Electric ZB6EB1A Complete body for pilot lights, Harmony XB6, white light block with body fixing collar with integral LED 12...24V
Schneider Electric ZB6EB1A Complete body for pilot lights, Harmony XB6, white light block with body fixing collar with integral LED 12...24V
- MPN: ZB6EB1A
- PPN: SCH-ZB6EB1A
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$22.42/ EA
Description
Complete body for pilot lights, Harmony XB6, white light block with body fixing collar with integral LED 12...24V
Specifications
Environment
- Product Certifications
- CSA || GOST || CCC || UL
- Resistance To Electromagnetic Fields
- 10 V/m IEC 61000-4-3
- Shock Resistance
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Ambient Air Temperature For Storage
- -40-70 °C
- Electrical Shock Protection Class
- class II IEC 61140
- Resistance To Fast Transients
- 2 kV IEC 61000-4-4
Ambient Air Temperature For Operation-25-70 °C
StandardsJIS C 4520 || IEC 60947-5-1 || CSA C22.2 No 14 || IEC 60947-1 || JIS C 852 || IEC 60947-5-5 || UL 508
Vibration Resistance+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Resistance To Electrostatic Discharge6 kV on contact (on metal parts) IEC 61000-2-6 || 8 kV in free air (in insulating parts) IEC 61000-2-6
Protective TreatmentTC
Electromagnetic Emissionclass B IEC 55011
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Circularity Profile
- N/A
Mercury FreeYes
China Rohs RegulationX
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Complementary
- Terminals Description Iso N°1
- (X1-X2)PL
- [Uimp] Rated Impulse Withstand Voltage
- 4 kV IEC 60947-1
- Current Consumption
- 15 mA
- [Ui] Rated Insulation Voltage
- 250 V 3)IEC 60947-1
- Supply Voltage Limits
- 6-30 V AC/DC
- Cad Overall Depth
- 58 mm
Net Weight0.003 kg
Cad Overall Height16 mm
Surge Withstand1 kV in contact IEC 61000-4-5 || 2 kV in free air IEC 61000-4-5
Signalling Typesteady
Operating Positionany position
Specifications
- [Us] Rated Supply Voltage
- 12...24 V AC/DC
- Light Source
- LED
- Product Or Component Type
- complete body for pilot lights
- Sale Per Indivisible Quantity
- 5
- Device Short Name
- ZB6
Range Of ProductHarmony XB6
Light Block Supplydirect
Connections - Terminalspins for printed circuit board 1 x 0.5 mm
Light Source Colourwhite
Bulb Baseintegral LED
