Square D 9001KYK32 Harmony 9001K Control Station, 2 Push-Buttons, NEMA 3/4/13
Square D 9001KYK32 Harmony 9001K Control Station, 2 Push-Buttons, NEMA 3/4/13
- MPN: 9001KYK32
- UPC: 785901040002
- PPN: SCH-9001KYK32
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$529.82/ EA
Description
This complete control station with two pushbuttons provides an ergonomic interface for your machines The control station is composed of two push-buttons with 3 NO + 3 NC (Up-Down-Stop), and it is connected to control circuits with classic screw-clamp connections It can be used indoor It is impact resistant, dust resistant, water resistant and vibration resistant, making it ideal for operation in harsh environments High performance International standards & certifications (Marine ABS certification, Type 3, 4 and 13)
Specifications
Complementary
- [Ie] Rated Operational Current Ac
- 10 A
- Connections - Terminals
- screw-clamp terminals
- Enclosure Material
- die cast zinc alloy grey
Enclosure/Cubicle Descriptionsurface mounting
Control Station Composition2 push-buttons 3 NO + 3 NC UP-DOWN-STOP
Type Of Installationindoor/outdoor
Offer Sustainability
- China Rohs Regulation
- X
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP121027EN
- Toxic Heavy Metal Free
- Yes
- Reach Regulation
- Free of Substances of Very High Concern above the threshold
Circularity ProfileN/A
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
Reach Free Of SvhcYes
Specifications
- Contact Block Name
- KA1
- Provided Equipment
- contact block || legend plate
- Device Short Name
- KY
Range Of ProductHarmony 9001K
Product Or Component Typecomplete control station
Environment
- Nema Degree Of Protection
- NEMA 3/4/13
