Burndy YAGB25LTC516FXOEM Copper Tubing Hylug, 1/0 AWG, 5/16 Inch Stud, 35 kV Rating
- MPN: YAGB25LTC516FXOEM
- UPC: 781810547441
- PPN: BUR-30008167
CAD
$20.89
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Cu Tubing Hylug, 1/0 AWG, 5/16 IN Stud
Documentation & Downloads
Specifications
Dimensions
| Dimension - Bolt Hole Size inch | 0.31 in |
|---|---|
| Dimension - L Length Overall mm | 49 mm |
| Dimension - Pad Width inch | 0.83 in |
| Dimension - Bolt Size fraction | 5/16 |
|---|---|
| Dimension - Length Overall inch | 1.92 in |
Certifications and Compliance
| Certification - CSA Approved | No |
|---|---|
| Certification - UL Recognized | No |
| Standards - RoHS Compliance Status | CM |
| UL Listed | No |
| Certification - ETL | No |
|---|---|
| Certification - cULus | No |
| Standards - RoHS Compliant | Yes |
Conductor Related
| Conductor - Copper Str Size | 1/0 |
|---|
| Conductor Type | CU C Str-Size |
|---|
General
| Application | Power Connector |
|---|---|
| Plating Type | Tin - Electro Plated |
| Type | OEM Terminals |
| UPC 12 Digit | 7818105474411 |
| Connector Type | Terminal |
|---|---|
| Trade Name | HYLUG™ |
| UPC | 781810547441 |
Electrical Ratings
| Rating - KVA | 35 kV |
|---|---|
| Voltage - Maximum | 35000 |
| Rating - Minimum Voltage | 600 |
|---|
