Brady DAT-54-642-10 DATAB Series Tedlar Self-Laminating Labels, 1.437" H x 1" W, Pack of 10000 Labels
- MPN: DAT-54-642-10
- UPC: 662820289180
- PPN: BRD-DAT-54-642-10
- UNSPSC: 55121612
CAD
$2819.00
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The B-642 is a thin tape with self-extinguishing properties that has excellent flexibility for wrapping on small diameter wires.
Features
- Ideal for use in aerospace, defense and mass transit industries
- The polyvinylfluoride film provides good self-extinguishing properties and solvent resistance
- For use in dot matrix and thermal transfer printers
Documentation & Downloads
Specifications
Key Specifications
- Applications
- Wire and Cable Labeling
- Color
- Clear/White
- Enables Industry Compliance
- ASTM B 117; ASTM D 1000; ASTM D 2979; ASTM G 155
- For Use with Printer
- Dot Matrix Printers
- Primary Noun, Basic Function
- Label
- Printer and Label Applications
- Wire & Cable
- Quantity per Roll
- 10000
- Ribbon Series
- R2000; R5000
- Suggested Ribbon Series
- R5000
- Total Quantity
- 10000
- Adhesive Type
- Permanent Acrylic
- Indoor or Outdoor Use
- Outdoor Use
- Material
- Polyvinylfluoride
- Overlaminate Included
- Overlaminate Included
- SAP B-Number
- B-642
- Dimensions (Metric)
- 25.40 mm W x 36.50 mm H
- Height (in/ft/yd)
- 1.437 in
- Horizontal Repeat
- 1 in
- Label/Tape Size (in/ft/yd)
- 1.437 in H x 1 in W
- Maximum Service Temperature °F
- 248 °F
- Maximum Wire Diameter (mm/cm/m)
- 7.62 mm
- Minimum Application Temperature °F
- 50 °F
- Minimum Service Temperature °F
- -94 °F
- Minimum Wire Diameter (mm/cm/m)
- 3.81 mm
- Printable Area Dimensions (Metric)
- 12.70 mm H x 25.40 mm W
- Printable Area Height (mm/cm/m)
- 12.70 mm
- Printable Area Width (mm/cm/m)
- 25.40 mm
- Size - Width (mm)
- 25.40 mm
- Thickness (mm/cm/m)
- 0.055 mm
- Vertical Repeat (mm)
- 38.1 mm
- Web Width (mm/cm/m)
- 228.60 mm
- Width (mm/cm/m)
- 25.4 mm
Brand NameBrady®
Compatible Surface TypesGeneral
FinishMatte
Label/Media FormatPack
Print TechnologyDot Matrix
Printer CompatibilityDot Matrix
Quantity per Row8
ShapeRectangle
Total Qty per Pack10000 Label(s) / Pack
Trade NameDATAB®
Brady Material NumberB-642
Label PropertiesSelf Laminating Labels & Wraps
Material PropertiesFlame-retardant; Self-laminating
Resistance PropertiesCorrosion-Resistant; Humidity-Resistant; UV-Resistant; Weather-Resistant
Dimensions1.437 in H x 1 in W
Dimensions 21.437 in H x 1 in W
Height (mm/cm/m)36.50 mm
Horizontal Repeat (mm)25.4 mm
Maximum Service Temperature °C120 °C
Maximum Wire Diameter (in/ft/yd)0.30 in
Minimum Application Temperature °C10 °C
Minimum Service Temperature °C-70 °C
Minimum Wire Diameter (in/ft/yd)0.15 in
Printable Area Dimensions0.5 in H x 1 in W
Printable Area Height (in/ft/yd)0.5 in
Printable Area Width (in/ft/yd)1 in
Sign Size-General1.437 in x 1 in
Thickness (in/ft/yd)0.0022 in
Vertical Repeat1.5 in
Web Width (in/ft/yd)9 in
Width (in/ft/yd)1 in
Wire Diameter Range0.15 in to 0.30 in
Regulatory Information
- Contains CA PROP 65 Substance
- Yes Contains-Label not req.
- Contains Heavy Metal(s)
- Unavailable
- EU RoHS Compliance
- Pass 2011/65/EU
- SDS Safety Data Sheet required
- No = MSDS/SDS is not required
Contains CA PROP 65 SubstanceNo
DOT Regulated ProductNo = not regulated by DOT
EU RoHS CompliantYes
