Brady 3PS-187-2-BK-S-4 Double Sided PermaSleeve Polyolefin Wire Marking Sleeves, 0.187" Dia x 0.5" W, Black

MPN: 3PS-187-2-BK-S-4
UPC: 662820023098
PPN: BRD-3PS-187-2-BK-S-4
UNSPSC: 55121612

$661.99

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

PermaSleeve Heat Shrink Tubing is engineered for thermal transfer or dot matrix printing and is ideal for use in wire identification.

Documentation & Downloads

Specifications

Key Specifications

Applications	Wire and Cable Labeling
Color	Black
Finish	Matte
Label/Media Format	Roll
Max. Lines of Text	2
Print Technology	Thermal Transfer
Printer and Label Applications	Wire & Cable
Printer Compatibility (Print)	BBP72
Quantity per Row	4
Ribbon Series	R6700-WT
Shrink Ratio	3:1
Suggested Ribbon Series	R4502S; R6700
Total Quantity	2000
Brady Material Number	B-342
Material	Heat-shrink Polyolefin
Resistance Properties	Chemical-Resistant; Corrosion-Resistant; Humidity-Resistant; Smear-Resistant; UV-Resistant; Weather-Resistant
Core Diameter (mm/cm/m)	76.20 mm
Diameter as Supplied (mm/cm/m)	4.8 mm
Dimensions (Metric)	12.70 mm W x 8.50 mm H
Height (in/ft/yd)	0.335 in
Maximum Service Temperature °C	135 °C
Maximum Wire Diameter (in/ft/yd)	0.15 in
Maximum Wire Gauge	10 AWG
Minimum Service Temperature °F	-67 °F
Minimum Wire Diameter (mm/cm/m)	1.57 mm
Recovered Diameter (in/ft/yd)	0.062 in
Roll Width (in/ft/yd)	2 in
Size - Width (mm)	12.70 mm
Sleeve Size (mm/cm/m)	4.8 mm Dia x 12.7 mm W
Sleeve Width (mm/cm/m)	12.7 mm
Vertical Repeat (mm)	15.88 mm
Wire Diameter Range	0.062 in to 0.15 in

Brand Name	Brady®
Enables Industry Compliance	ASTM D 2671; ASTM E 162; ASTM E 662; ASTM G 155; MIL-STD-202; SAE-AMS-DTL-23053; SAE-AS-81531; UL Recognized
For Use with Printer	BBP®72 Label Printer; BRADY IP® Series Label Printer; BradyPrinter i5100; BradyPrinter i7100; BRADYPRINTER PR Plus Series Label Printer; THT 3" Core Printer
Markers per Roll	500
Primary Noun, Basic Function	Sleeve
Printable Sides	Double-Side Printable
Printer Compatibility	BBP72
Quantity per Roll	2000
Recommended Ribbon	IP-R6700-WT; R6700-WT
Shape	Rectangle
Sleeve Slits	Yes
Total Qty per Pack	2000 Sleeve(s) / Roll
Trade Name	PermaSleeve®
Label Properties	Heat Shrink Sleeves
Material Properties	Flame-retardant; Heat-shrinkable
SAP B-Number	B-342
Diameter as Supplied (in/ft/yd)	0.187 in
Dimensions	0.335 in H
Dimensions 2	0.335 in H
Height (mm/cm/m)	8.50 mm
Maximum Service Temperature °F	275 °F
Maximum Wire Diameter (mm/cm/m)	3.81 mm
Minimum Service Temperature °C	-55 °C
Minimum Wire Diameter (in/ft/yd)	0.062 in
Minimum Wire Gauge	20 AWG
Recovered Diameter (mm/cm/m)	1.6 mm
Roll Width (mm/cm/m)	50.8 mm
Sleeve Size (in/ft/yd)	0.187 in Dia x 0.5 in W
Sleeve Width (in/ft/yd)	0.5 in
Vertical Repeat	0.625 in
Web Width (mm/cm/m)	89.00 mm
Wire Gauge Range	20 AWG to 10 AWG

Regulatory Information

CA Prop 65 Labeled	Yes
Contains CA PROP 65 Substance	Yes Contains-Label required
Contains CA PROP 65 Warning Type	Cancer
Contains Heavy Metal(s)	Unavailable
EU RoHS Compliance	Pass 2011/65/EU(Pass 2015/863)
SDS Safety Data Sheet required	No = MSDS/SDS is not required

CA Prop 65 Label Warning	WARNING: Cancer - www.P65warnings.ca.gov
Contains CA PROP 65 Substance	Yes
Contains CA Prop 65 Cancer Causing Chemical	Antimony Trioxide
DOT Regulated Product	No = not regulated by DOT
EU RoHS Compliant	Yes
