Bussmann

Bussmann FNM-2 Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V

Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V
Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V
  • MPN: FNM-2
  • UPC: 051712520201
  • PPN: BUS-FNM-2

Spec sheet

In Stock

Company Stock:

00

Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

Looking to buy a large quantity?

To view product inventory

CAD$7.57/ EA

Description

Eaton Bussmann series FNM fuse, Time-delay Midget fuse, 2 A, Dual, Non-indicating, Ferrule end x ferrule end, 100 AIC at 250 Vac,10 kAIC at 125 Vac, Nickel-plated bronze endcap, Standard, 250 V

Features

  • Engineered with a sophisticated dual-element design, this 2-amp fuse provides the critical time-delay necessary to withstand temporary, high-voltage inrush currents from small motors and transformers. This prevents annoying "nuisance" blowing during equipment startup, ensuring your industrial machinery or HVAC controls remain operational while still providing a rapid response to dangerous short circuits.
  • Designed to the universal "midget" fuse form factor (10x38mm), the FNM-2 is a drop-in replacement for a wide variety of supplemental overcurrent protection applications. Its compact, fiber-tube construction makes it the ideal choice for space-constrained control panels, solenoid circuits, and lighting ballasts where high-performance protection is required in a small footprint.
  • Optimized for circuits rated up to 250 volts, this Bussmann Fusetron™ fuse delivers high-level protection for sensitive electronic components and secondary control circuits. By utilizing a fuse specifically rated for higher voltage environments, you prevent internal arcing during a fault, shielding your expensive control boards and pilot devices from catastrophic electrical failure.
  • Fully compliant with UL 248-14 and CSA C22.2 standards, this fuse is rigorously tested to ensure it clears faults within specified timeframes. Using a certified Bussmann component ensures your installation remains code-compliant for building inspections and provides the peace of mind that your facility is protected by the industry standard in electrical safety and reliability.

Specifications

Voltage Rating
250 V
Interrupting Rating
100 AIC at 250 Vac, 10kA at 125 Vac.
Size
0.41 in x 1.5 in
Material
Nickel-plated bronze endcap
Fuse Indicator
Non-indicating
Product Weight
0.2 lb
Amperage2 A
Fuse TypeTime-delay Midget
ConnectionFerrule end x ferrule end
Number of ElementsDual
ComplianceCE Marked, UL Listed, CSA Certified, RoHS Compliant
