Bussmann FWA-45A21F High Speed Fuse 500V AC/DC 45A 100 kAIC Cylindrical Ferrule End
- MPN: FWA-45A21F
- UPC: 051712795272
- PPN: BUS-FWA-45A21F
CAD
$69.90
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
High Speed Fuse 500V AC/DC 45A 100 kAIC Cylindrical Ferrule End
Documentation & Downloads
Specifications
Key Specifications
| Fuse indicator | Non Indicating |
|---|---|
| Construction size | Other |
| Connection | Ferrule end x ferrule end |
| Amperage Rating | 45 A |
| Utilization category | aR (accompanied semiconductor protection) |
| Type | High speed fuse |
| Breaking capacity | 200 A |
| Pre arc (I2T) | 130 |
| Application | DC common bus, DC drives, power converters/rectifiers and reduced voltage starters |
| Packaging type | Standard |
| Interrupt rating | 100 kAIC |
|---|---|
| Clearing (I2T) | 1300 at 150 V |
| Release characteristic | Other |
| Frequency rating - max | 62 Hz |
| Watt losses | 6 W |
| Fuse shape | Cylindrical |
| Frequency rating - min | 45 Hz |
| Voltage rating | 150 V |
| Voltage type | AC/DC |
General
| UPC | 051712795272 |
|---|---|
| Product Length/Depth | 51 mm |
| Product Width | 21 mm |
| Warranty | Not Applicable |
| Certifications | CSA Certified |
| EAN | 5027590499279 |
|---|---|
| Product Height | 21 mm |
| Product Weight | 55.3 g |
| Compliances | CE Marked |
