Bussmann

Bussmann FWH-25A14F Eaton Bussmann series FWH high speed fuse, 25A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end

Eaton Bussmann series FWH high speed fuse, 25A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
Eaton Bussmann series FWH high speed fuse, 25A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
  • MPN: FWH-25A14F
  • UPC: 051712370837
  • PPN: BUS-FWH-25A14F

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$37.48/ EA

Description

Eaton Bussmann series FWH high speed fuse, 25A, 200 kAIC Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end

Specifications

General

UPC
051712370837
Product Length/Depth
55 mm
Product Width
73 mm
Warranty
Not Applicable
Certifications
UL Recognized
EAN5027590499590
Product Height32 mm
Product Weight20.4 g
CompliancesCE Marked

Specifications

Fuse indicator
Non Indicating
Construction size
14 mm x 51 mm
Connection
Ferrule end x ferrule end
Amperage Rating
25 A
Utilization category
aR (accompanied semiconductor protection)
Type
High speed fuse
Breaking capacity
200 A
Pre arc (I2T)
49
Application
protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
Packaging type
Standard
Interrupt rating50 kAIC at 500 Vdc
Clearing (I2T)191 at 500 V
Release characteristicOther
Frequency rating - max62 Hz
Watt losses7 W
Fuse shapeCylindrical
Frequency rating - min45 Hz
Voltage rating500 V
Voltage typeAC/DC
