Bussmann TR2/C515-1-R Time-Delay Fuse 1A, 250V, Glass Tube, Response Time 60 min max
- MPN: TR2/C515-1-R
- UPC: 051712650939
- PPN: BUS-TR2/C515-1-R
CAD
$1.23
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Time-Delay Fuse 1A, 250V, Glass Tube, Response Time 60 min max
Documentation & Downloads
Specifications
Key Specifications
- Height
- .217 IN
- Width
- .217 IN
- Type
- Electronic
- Voltage Rating
- 250V
- Interrupt Rating
- 35 AIC at 250 Vac, 10 kAIC at 125 Vac
- Material Type
- Glass tube, nickel-plated brass endcap
- Diameter
- 5.2 MM
- Used With
- Tin coated axial leads
- Resistance
- Typical: .14 ohms
- Fuse Indicator
- Non Indicating
Length.598 IN
Weight.003 LB
ApplicationElectronic circuits, printed circuit boards
Amperage Rating1A
ConnectionFerrule end X ferrule end
Packaging TypeStandard
Quantity1500 fuses packed into tape on a reel (20.3mm lead wire length)
Melting (L2T)Typical: 14.289 I2t
Voltage DropMaximum: 230 mV
Response Time60 min maximum at 135%, 3 s minimum at 135%, 120 s minimum at 200%
