Bussmann CGL-25 Current-limiting HRC Form II Fuse 600 Vac 250 Vdc 25A 40 kAIC Class C
- MPN: CGL-25
- UPC: 051712100311
- PPN: BUS-CGL-25
CAD
$36.67
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Eaton Bussmann series Tron CGL HRC form II Class C fuse, 600 Vac, 250 Vdc, 25A, 200 kAIC at 600 Vac, 40 kAIC 250 Vdc, Non Indicating, Current-limiting, HRC Form II, Blade end X blade end, Class C
Features
- Engineered for heavy-duty electrical loads, this 25 Amp fuse safely handles up to 600 Vac and 250 Vdc. This extensive voltage threshold allows you to confidently deploy it in demanding industrial control panels, motor starters, and transformer circuits without risking premature failure or circuit instability.
- Featuring an exceptional 200 kAIC and 40 kAIC DC interrupting rating, this HRC Form II fuse instantly clears massive fault currents. By rapidly isolating catastrophic overcurrent events, it prevents devastating equipment damage and safeguards nearby personnel from explosive arc flash hazards.
- This Class C (HRCII-C) fuse features standard offset blade-end connections with a total length of 3.31 inches (84.14 mm). It provides a precise drop-in fit for industrial Red Spot and compatible bolt-down fuse blocks, eliminating mounting delays and ensuring a secure, vibration-resistant connection.
- Fully certified to CSA, Class 1422, File 53787, and CE standards, this fuse guarantees strict adherence to North American and international safety regulations. Installing these code-compliant components streamlines your safety audits and inspection sign-offs, verifying that your machinery is protected by industry-approved electrical standards.
Documentation & Downloads
Specifications
Additional
- Amperage
- 25 A
- Interrupting Capacity
- 40 kAIC
- Class
- Class C
- Product Width
- .94 in
- Connection
- Blade end x blade end
- Fuse indicator
- Non-indicating
Voltage600 Vac, 250 Vdc
TypeCurrent-limiting, HRC Form II
Product Height3.31 in
Product Length/Depth.81 in
Product Weight.115 lb
