Schneider Electric ZBY9W2M101 Illuminated Legend Ring 230V Red LED 60 mm Round Label

  • MPN: ZBY9W2M101
  • PPN: SCH-ZBY9W2M101
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below

    • CAD

    $61.80

    / EA

    Available to Order

    Lead times may vary. For an accurate estimate please contact us.

    Available To Ship Immediately:0

    Loading dialog...

    Looking to buy a large quantity?

    To View Branch Inventory And Your Custom Pricing

    Spec sheet

    Description

    This circular legend provides clear labelling of your emergency stop devices. It is supplied ready engraved with a marking relevant to machine operation and is compatible with any standard 60mm Harmony emergency stop or switching off unit.

    Documentation & Downloads

    Specifications

    Key Specifications

    Country of Origin
    Indonesia

    Physical Attributes

    Light Source Color
    red

    Important Information Attributes

    Compatibility Code
    XB4, XB5
    Certificate Agency
    UL Listed, CSA
    Carbon Footprint Of The Distribution Phase [A4]
    0.02630453544813227, 0 kg CO2 eq.
    Carbon Footprint Of The Installation Phase [A5]
    0.002115302477519544, 0 kg CO2 eq.
    Carbon Footprint Of The Use Phase [B2 B3 B4 B6]
    97 kg CO2 eq., 97.0659581253825
    Local Publishable Date
    2026-01-12
    Stocking Flag
    Y
    Weee Scope
    Out
    Eoli Availability Display
    No need of specific recycling operations
    Reach Full Compliance Status Id
    CONTAINS_SVHC
    Rohs Eur In Scope
    No
    Rohs Eur Conformity Date
    1930
    China Rohs In Scope
    Yes
    With Recycled Cardboard
    No
    Product Contributes To Saved And Avoided Emissions
    No
    Bulb Base
    integral LED
    Electrical Insulation Class
    class II IEC 61140
    Label Dimensions
    Ø 60 mm
    Marking
    unmarked yellow
    Operator Additional Information
    with illuminated ring
    Product Or Component Type
    illuminated unmarked legend ring
    Range Of Product
    Harmony
    Resistance To Electrostatic Discharge
    4 kV on contact (on metal parts) IEC 61000-4-28 kV in free air (in insulating parts) IEC 61000-4-2
    Resistance To High Pressure Washer
    7000000 Pa 55 °C 0.1 m
    Sale Per Indivisible Quantity
    1
    Shape Of Signaling Unit Head
    round
    Software Version
    v6.3.0.1-4
    Sustainable Packaging
    No
    Vibration Resistance
    5 gn (f= 10-500 Hz) conforming to IEC 60068-2-625 mm peak to peak (f= 2-10 Hz) conforming to IEC 60068-2-6
    Pep Code
    ENVPEP2506032EN
    Pep Verification Date
    2025-06-30
    Psr Version
    PSR-0005-ed3.1-EN-2023 12 08
    Data Source
    extrapolated product
    Functional-unit Quantity
    1
    Reference Lifetime In Y
    10
    Energy Model - Installation [A5]
    No energy used
    Energy Model - End Of Life [C1-c4]
    Global, European and French datasets are used.
    Height Nominal
    60 mm
    [Ui] Rated Insulation Voltage
    250 V 3)EN/IEC 60947-1
    Cap/Operator Or Lens Colour
    red
    Package Weight(Lbs)
    21 g
    Warranty (In Months)
    18
    Shock Resistance30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27, 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
    [Us] Rated Supply Voltage230 V, 230...240 V AC 50/60 Hz
    Carbon Footprint Of The End-of-life Phase [C1 To C4]0 kg CO2 eq., 0.043119929873282635
    Carbon Footprint Of The Manufacturing Phase [A1 To A3]0.4 kg CO2 eq., 0.3663686578379308
    Local Data StatusPublishable
    Return IndicatorY
    Stock Policy2
    Scope PerimeterAt least in Europe
    Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
    Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
    Rohs Eur StatusCompliant By Exemption
    Rohs Eur Full Compliance StatusCompliant By Exemption
    China Rohs Label7
    Without Single Use PlasticNo
    Product Kit IdentifierN
    Current Consumption14 mA
    Electromagnetic Emissionclass B IEC 55011
    Light Sourceprotected LED
    Materialplastic
    Product AvailabilityNon-Stock - Not normally stocked in distribution facility
    Protective TreatmentTH
    Resistance To Electromagnetic Fields10 V/m IEC 61000-4-3
    Resistance To Fast Transients2 kV IEC 61000-4-4
    ReturnabilityYes
    Service Life100000 h at rated voltage and 25 °C
    Signalling Typesteady
    Supply Voltage Limits195-264 V AC
    Total Lifecycle Carbon Footprint98 kg CO2 eq.
    Light Source Colorred
    Database Version2024-01
    Pcr VersionPEP-PCR-ed4-2021 09 06
    Type Of Verification For The PepIndependent internal review
    Functional-unit DescriptionIlluminated ring uses to indicate clear status of emergency stop and pushbutton applications to improve operational efficiency during its 10 years of lifetime with a maximum power consumption of 0.432 W at 71% usage during 10 years lifetime.
    Functional-unit Unitunit
    Energy Model - Manufacturing [A1-a3]Electricity Mix; High voltage; 2020; Indonesia, ID
    Energy Model - Use [B6]Electricity Mix; Low voltage; 2020; Global, GLO
    Recyclability Potential In %3
    Width Nominal9.3 mm
    Accessory / Separate Part Destinationemergency switching off mushroom head push-button
    Nbr. Of Units In Pkg.1
    Take-backNo

    Environment Attributes Main

    Ambient Air Temperature For Operation
    -40-70 °C, -40-70 °C
    Ip Degree Of Protection
    IP66 IEC 60529, IP67 IEC 60529, IP69 IEC 60529IP69K ISO 20653Type 13 UL 50E, Type 12 UL 50E, Type 4 UL 50E, Type 4X UL 50E
    Recycled Metal Content At Cr Level
    0 %
    Mercury Free
    Yes
    Environmental Disclosure
    ENVPEP2506032EN
    Packaging Made With Recycled Cardboard
    No
    Reach Regulation
    Reference contains Substances of Very High Concern above the threshold
    Pep Verification Date
    2025-06-30
    Psr Version
    PSR-0005-ed3.1-EN-2023 12 08
    Ambient Air Temperature For Storage-40-70 °C, -40-70 °C
    Take BackNo
    China Rohs RegulationX
    Carbon Footprint97.50386655101936
    Eu Rohs DirectiveCompliant By Exemption
    Packaging Without Single Use PlasticNo
    Pep CodeENVPEP2506032EN
    Pcr VersionPEP-PCR-ed4-2021 09 06
    Type Of Verification For The PepIndependent internal review

    General Attributes

    Product Or Component Type
    illuminated unmarked legend ring
    Range Of ProductHarmony

    ETIM

    ETIM 8
    EC000624
    ETIM 9EC000624

    Surge Protection And Filtering Attributes

    Surge Withstand
    1 kV IEC 61000-4-5

    Contractual Warranty Attributes

    Warranty Period
    18 months
    Warranty18 months

    Overview Attributes

    Device Presentation
    intermediate ring
