Blackburn U102-YR Insulated Aluminum Compression Splices, 3-1/4 Inch Long, for 1/0 & #2 Conductors

Insulated Aluminum Compression Splices, 3-1/4 Inch Long, for 1/0 & #2 Conductors
Insulated Aluminum Compression Splices, 3-1/4 Inch Long, for 1/0 & #2 Conductors
  • MPN: U102-YR
  • PPN: T-B-U102-YR

Spec sheet

In Stock

Company Stock:

00

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$4.92/ EA

Description

Insulated Aluminum Service Entrance Compression Splices - U 5/8 inch die series - longer length 3-1/4 inch long, Conductor A: Yellow, 1/0 Stranded, 1/0 compact, 1/0 compressed, Conductor B: Red, #2 Stranded, #2 compact, #2 compressed

Specifications

North American Specifications (UNSPSC)

UNSPSC
39121449 Wire or cable compression splice
Brand Name
Blackburn
Special Features
Solid center barriers and large chamfers. Easy cable installation. Pre-filled with oxide inhibitor to prevent oxidation and keep out moisture. Constructed from Aluminum. Provides high conductivity. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized -Nylon Sleeves Rresist Installing-Tool Pressure and Provide Reliable 600V Insulation.
Standard
ANSI C119.4
Connection
Crimp/Compression
Number Of Conductors
2
Color
Yellow/Red
IGCC4669 Wire or cable compression splice
TypeInsulated Aluminum Service Entrance Compression Splices
ApplicationFor Compact Conductors
Size3-1/4 inches long
Conductor RangeSide A 1/0 Stranded/Compact/Compressed. Side B #2 Stranded/Compact/Compressed.
MaterialAluminum
InsulationInsulated

Packaging

Inner Quantity
100
Outer Dimensions (inches)
1x1x1
Outer Quantity500
Weight Uom1 lbs. Each
