ABB 2TLA020001R1100 JSHD2C type A Three-position single pushbutton
ABB 2TLA020001R1100 JSHD2C type A Three-position single pushbutton
- MPN: 2TLA020001R1100
- PPN: ABB-2TLA020001R1100
- UNSPSC: 39122216
Spec sheet
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$132.86/ EA
Description
The JSHD2C Type A is a three-position pushbutton with gold plated contacts and 3 leads, each 190 mm. The force needed to actuate the push-button from middle to bottom is 17 N.
Specifications
Dimensions
- Product Net Depth / Length
- 13.5 mm
- Product Net Width
- 26.55 mm
Product Net Height29.25 mm
Product Net Weight0.01 kg
Safety Information
- Certification Agency
- CEcURusKiwa
Technical
- Communication Interface
- Contacts
- Number of Contacts NC
- 1
- Rated Operational Current DC-12 (Ie)
- (24 V) 0.02 A
Connection Configuration3 leads, 190 mm each
Number of Contacts NO1
Technical InformationFoff: 17 N; Mechanical service life: > 1 million cycles, top to middle position, > 100 000 cycles, middle to bottom position
Classifications
- eClass
- V11.0 : 27371238
- IDEA Granular Category Code (IGCC)
- 5210 >> Push button switch
ETIM 9EC002571 - Agreement switch
Object Classification CodeB
Environmental
- Ambient Air Temperature
- Operation -25 ... +55 °CStorage -40 ... +85 °C
- Material
- Contact: AuHousing: POM 20% GF (yellow)Plunger: PBT (Black)
Degree of ProtectionIP54
Ordering
- Minimum Order Quantity
- 1 piece
- Product Main Type
- JSHD2
- Function
- Three-position single pushbutton
Customs Tariff Number85369095
Product NameThree-position single pushbutton
Status IndicatorNo
