Telemecanique Sensors 9007AP323 Snap limit switch, 9007, parallel roller plunger, NO/NC, bushing mount, oiltight
- MPN: 9007AP323
- UPC: 785901820536
- PPN: TES-9007AP323
- UNSPSC: 39122209
CAD
$175.30
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Snap limit switch, 9007, parallel roller plunger, NO/NC, bushing mount, oiltight
Documentation & Downloads
Specifications
Key Specifications
| Series Name | heavy duty |
|---|---|
| Range Of Product | 9007 |
| Device Short Name | 9007AO/CO |
| Body Type | fixed |
|---|---|
| Product Or Component Type | snap limit switch |
Complementary
| Switch Actuation | by 30° cam |
|---|---|
| Height | 2.5 in |
| Mounting Mode | panel mounting oil tight |
| [Ui] Rated Insulation Voltage | 600 V 3)UL 508 contact block || 600 VCSA C22.2 No 14 contact block |
| Positive Opening | without |
| Contact Operation | snap action |
| [Ie] Rated Operational Current | 5 A 600 V AC, A600 NEMA rating designation || 6 A 480 V AC, A600 NEMA rating designation || 10 A 240 V AC, A600 NEMA rating designation || 15 A 120 V AC, A600 NEMA rating designation || 0.02 A 600 V DC || 0.2 A 250 V DC || 0.5 A 125 V DC |
| Contacts Material | silver contacts |
| Type Of Operator | spring return roller plunger steel bushing mounted |
| Body Material | cast zinc |
| Contact Form | Form Z |
| Minimum Force For Tripping | 1.75 lbf |
| Depth | 2.69 in |
| Net Weight | 0.1 lb(US) |
| Type Of Approach | traverse approach, 2 directions |
|---|---|
| Movement Of Operating Head | linear |
| Terminals Description Iso N°1 | (3-4)NO || (1-2)NC |
| Electrical Connection | 1-2 6 binder head screw terminals AWG 22...AWG 14) |
| Number Of Steps | 1 |
| Operator Material | cast zinc |
| Fixing Mode | by the head |
| Maximum Force For Tripping | 1.75 lbf |
| Operator Profile | plunger head |
| [Ithe] Conventional Enclosed Thermal Current | 15 A |
| Contacts Type And Composition | NC-NO SPDT-DB |
| Width | 0.83 in |
| Material | metal |
| Number Of Poles | 1 |
Environment
| Ambient Air Temperature For Operation | -20-185 °F |
|---|---|
| Nema Degree Of Protection | NEMA 1 Nema type 250 |
| Ambient Air Temperature For Storage | -20-185 °F |
|---|---|
| Ip Degree Of Protection | IP20 conforming to IEC 60529 |
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Environmental Disclosure | ENVPEP111160EN |
|---|---|
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Eu Rohs Directive | Not applicable, out of EU RoHS legal scope |
|---|---|
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
