Hubbell Wiring Device-Kellems HBL23CM23 Twist-Lock Insulgrip Connector 20A 250V AC 2-Pole Corrosion Resistant
- MPN: HBL23CM23
- UPC: 783585038124
- PPN: HBL-HBL23CM23
- UNSPSC: 39121421
CAD
$82.11
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Locking Devices, Twist-Lock®, Corrosion Resistant Insulgrip® Connector, 20A, 250V AC, 2 Pole, 3 Wire Grounding, Yellow
Features
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- Integral dust shield protects wiring chamber from dust or contaminants
- Corrosion Resistant
Specifications
Key Specifications
- Engineering Drawing 1 Display Text
- HBL23CM23 AutoCAD Drawing
- Current / Amperage Rating
- 20 A
- Height
- 2.26 in
- Length
- 3.86 in
- Standards - RoHS Compliance Status
- CM
- Application
- Heavy Duty Industrial
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- NEMA Rating
- L6-20R
- Size
- 3.86 in x 2.26 in x 2.26 in
- Standard
- Certified to CSA C22.2 No.42;Fed.Spec. W-C-596;Listed to UL 498
- Voltage Rating
- 250 VAC
- Weight
- 0.30 lb.
- Connectivity
- Pressure Terminal Screws
- Display Size
- Standard
- Number Of Poles
- 2-Pole
- Operating Temperature
- Maximum continuous 75°C and minimum -40°C without Impact
- Class Code
- A08
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Replaced Catalog Number
- 2323CY
- Cord Range
- 0.360"-0.930" (9-24)
- Current Rating
- 20 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 11.450 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 30 EA
- Each - Pack Description
- Each
- NAICS Code
- 335931A102
Country of OriginUnited States
Dimensions3.86 in x 2.26 in x 2.26 in
Industry Standard(s)Certified to CSA C22.2 No.42;Fed.Spec. W-C-596;Listed to UL 498
PerformanceElectrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - HB or better per UL94 or CSA 22.2 No. 0.6;Environmental - Moisture Resistance - IP20 Suitability;Environmental - Operating Temperatures - Maximum Continuous 75°C Minimum -40°C (w/o impact);Mechanical - Terminal Accommodation - #16 AWG - #8 AWG stranded copper wire only.;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498
Amperage Rating20 A
ColorYellow
InsulationInsulated Body
Number of Poles2-Pole
Special FeaturesCorrosion Resistant
Temperature RatingMaximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact, -25° with impact.
Voltage Rating Description250 VAC
Width2.26 in
Dielectric StrengthWithstands 2,000V minimum
Nema RatingL6-20R
Number Of Wires3-Wire Grounding
Wire Size#16 AWG to #8 AWG
Description - InvoiceLKG CONN, CM, 20A 250V, L6-20R, YL
Harmonization Code8536690200
MSDS FlagNo
Sub Class CodeA08A110
Material - Mounting HardwareCord Mounted
MaterialNylon
BOX SIZE8.000x12.700x9.000 (in)
Carton - Number of Sub Packs10
Carton - SCC-14 Next Lower Level Sub Pack783585038124
Case Weight11.650 lb.
Lowest Level UOMEach
