Pass & Seymour LSCLDC163P CFL/LED/Incandescent Dimmer with Fan Control, 150W LED, 300W Incandescent, Brown
- MPN: LSCLDC163P
- UPC: 785007040456
- PPN: P-S-LSCLDC163P
CAD
$75.54
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
CFL/LED/Incandescent Dimmer with Fan Control, 150W LED, 300W Incandescent, Brown
Features
- CFL/LED dimmable bulb compatible (except for 0-10V LED drivers)
- Single pole/3-way versions
- Unique integrated single pole/3-way dimmer with fan speed control
- Ratings: 150W LED & CFL: 300W Incandescent: 1.6A (Fan Control): 120VAC 60Hz
Documentation & Downloads
Specifications
Key Specifications
- Depth
- 1.28 in
- Preset
- Yes
- Width
- 2.5 in
- Country of Origin
- China
- Voltage
- 120 VAC
- Switch Type
- Rocker
- Load Type
- Fan Motor
- Features
- Combination
- Frequency Rating
- 60 Hz
- Mounting Type
- Wall Box
- Wire Size
- #14 - #10 AWG
- Product Series
- Trademaster
- Features
- De-Hummer Fan Control
- Color
- Brown
- Material
- Steel,Thermoplastic
- Features
- Low-End Trim (Dim Range)
- Load Rating
- 120V 1.25A 150W (LED)
- Number of Poles
- Single Pole 3-Way
- Dimming Compatibility
- Forward Phase
- Load Rating
- 120V 300W (Incandescent)
- Special Features
- The industry's first CFL/LED dimmer with fan speed control works with select dimmable CFL/LED or incandescent lighting loads and features a sleek, sculpted ergonomic design for smooth, easy operation and precise control. Preset.
Height4.19 in
Load TypeCFL
Load TypeLED
StandardRoHS
Load TypeHalogen
Switch TypeSlider
Speed Range3-Speed
Indoor/OutdoorIndoor
Load TypeIncandescent
Number of Switches2.0
Requires Neutral WireNo
Application SectorResidential
Load Rating120V 300W (Halogen)
FinishMatte
Product LinePass & Seymour
Load Rating120V 1.25A 150W (CFL)
Load Rating120V 1.6A (FAN MOTOR)
Wire Connection TypeFlying Leads
Environmental ConditionsIndoor Only
Warranty TypeLimited Lifetime Warranty
