Square D 9999SM1 NEMA Motor Starter Contactor Type S with Mechanical Interlock, Size 00-1, 2-3 Pole
Square D 9999SM1 NEMA Motor Starter Contactor Type S with Mechanical Interlock, Size 00-1, 2-3 Pole
- MPN: 9999SM1
- UPC: 785901873600
- PPN: SCH-9999SM1
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$230.83/ EA
Description
Type S reversing magnetic contactors and starters are used for starting, stopping and reversing AC motors. Type S reversing contactors and starters are availble in NEMA Sizes 00 through 7. Type S contactors or starters can be mechanically interlocked so that only one device is energized at a time. The mechanical interlock is an interference (non-jamming) type, locking at the beginning of the stroke of any starter or contactor. The mechanical interlock is mounted on the underside of the reversing baseplate. This mechanical interlock is for two Type S contactors mounted horizontally. The mechanical interlock can be used with two NEMA Size 00, 0 or 1 two or three pole contactors. The 9999SM1 mechanical interlock is UL Listed and UL Component Recognized.
Specifications
Environment
- Product Certifications
- UL recognized || UL listed
Specifications
- Range Of Product
- type S
- Product Destination
- contactor || starter
Product Or Component Typemechanical interlock
Complementary
- Nema Size
- 0 || 1 || 00
- Number Of Poles
- 2.3
Mounting Positionhorizontal
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
Eu Rohs DirectiveUnder investigation
