Telemecanique Sensors XEP3S2W3 Microswitch, Limit switches XC Standard, miniature limit switch, low force cont, flat plunger, 6.35 mm cable clip tags
- MPN: XEP3S2W3
- PPN: TES-XEP3S2W3
CAD
$13.88
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Microswitch, Limit switches XC Standard, miniature limit switch, low force cont, flat plunger, 6.35 mm cable clip tags
Documentation & Downloads
Specifications
Key Specifications
| Movement Of Operating Head | linear |
|---|---|
| Electrical Connection | 6.35 mm cable clip tags |
| Product Or Component Type | microswitch |
| Switch Actuation | on end |
| Contacts Type And Composition | 1 C/O very low force |
| Contact Operation | snap action |
| Type Of Operator | plunger |
| Range Of Product | OsiSense XC |
|---|---|
| Contacts Material | AgNi |
| Head Type | plunger head |
| Series Name | special format |
| Type Of Approach | vertical approach |
| Detector Design | miniature, DIN 41635 A format |
| Device Short Name | XEP3 |
Complementary
| Height | 16 mm |
|---|---|
| Inter Contact Distance | 0.4 mm |
| Minimum Release Force | 0.05 N lever fixing position in A || 0.05 N lever fixing position in B || 0.05 N lever fixing position in C |
| Net Weight | 5.6 g |
| Maximum Differential Travel | 0.35 mm lever fixing position in A || 0.35 mm lever fixing position in B || 0.35 mm lever fixing position in C |
| Body Material | polyester |
| Maximum Force For Tripping | 0.25 N lever fixing position in A || 0.25 N lever fixing position in B || 0.25 N lever fixing position in C |
| Width | 10 mm |
| Terminals Description Iso N°1 | (1-2-4)OC |
|---|---|
| Minimum Over Travel | 1.1 mm lever fixing position in A || 1.1 mm lever fixing position in B || 1.1 mm lever fixing position in C |
| [Ith] Conventional Free Air Thermal Current | 5 A 250 V 50/60 Hz |
| Maximum Permissible End Of Travel Force | 20 N lever fixing position in A || 20 N lever fixing position in B || 20 N lever fixing position in C |
| Mechanical Durability | 50000000 cycles |
| Tripping Point | 14.7 mm lever fixing position in A || 14.7 mm lever fixing position in B || 14.7 mm lever fixing position in C |
| Contact Code Designation | B300, AC-15 (Ue = 240 V, Ie = 1.5 A)EN/IEC 60947-5-1 appendix A || D300, AC-15 (Ue = 240 V, Ie = 0.3 A)EN/IEC 60947-5-1 appendix A |
| Depth | 28 mm |
Environment
| Ambient Air Temperature For Operation | -25-125 °C |
|---|---|
| Marking | CE |
| Standards | IEC 60947-5-1 || UL 1054 || cURus || EN 60947-5-1 || EN 61058 |
|---|---|
| Ip Degree Of Protection | IP40 |
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Environmental Disclosure | ENVPEP110614EN |
| Toxic Heavy Metal Free | Yes |
| California Proposition 65 | WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
| Mercury Free | Yes |
|---|---|
| Sustainable Offer Status | Green Premium product |
| Reach Regulation | Free of Substances of Very High Concern above the threshold |
| Reach Free Of Svhc | Yes |
