Wiegmann WA121206GSC N4 Gasketed Screw-Cover 12X12X6 Carbon Steel - Gray
- MPN: WA121206GSC
- UPC: 786725310357
- PPN: HBL-WA121206GSC
- UNSPSC: 39121324
CAD
$396.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
N4 Gasketed Screw-Cover 12X12X6 Carbon Steel - Gray
Features
- Bodies and covers fabricated from 14 gauge carbon steel
- Seams are continuously welded and ground smooth
- Cover contains closed cell oil resistant neoprene gasket
- Enclosure comes with stainless steel cover screws which thread into sealed wells to prevent liquid, dust, etc. from entering into the box through the screw holes
- Ground stud located in door
- No holes, knockout, or rear mounting holes
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Mexico
- Actual Height
- 6.500 in
- Application
- Designed for use as wiring box, junction box, pull box, and terminal box in many indoor or outdoor applications where dust or moisture is a problem.
- Cover Type
- Screw Cover
- Depth
- 7 in
- Height
- 7 in
- Standard
- cULus
- Width
- 13 in
- Engineering Drawing 3 Display Text
- MOD Center Drawings Instructions
- Material type
- Galvanized Steel
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- SC,BOX,GASKETED,MP,SW,12X12X6
- Harmonization Code
- 7326908688
- Lead Time
- 21 wk
- Order Multiple
- 1 EA
- Stock Indicator
- S - Shelf Stock
- UL Listed
- Yes
- Material
- Carbon Steel
- BOX SIZE
- 7.000x13.000x13.000 (in)
- Carton - Number of Sub Packs
- 1
- Carton - SCC-14 Next Lower Level Sub Pack
- 00786725310357
- Pallet Height
- 42.000 in
- Pallet Weight
- 625.000 lb.
- NAICS Code
- 3359326101
Actual Depth6.5 in
Actual Width12.630 in
ColorAnsi-61 Gray Textured
Cubic Capacity637 cu.in
FinishTextured
NEMA Rating4
TypeEnclosure
Weight14 lb.
Finish TypeTextured
Nema Rating4
Class CodeP01
Freight Class Code06316009
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
Sub Class CodeP01P006
ConstructionContinuously Welded Seams
Base Unit of MeasureEA
Carton - Gross Weight per Pack14.000 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1 EA
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- Buy American Compliant
- Contact Manufacturer
- EU RoHS Indicator
- Yes
Certified ListedcULus
ListingsUL
