Wiegmann WA081004GSC N4 Gasketed Screw-Cover 8X10X4 Carbon Steel - Gray
- MPN: WA081004GSC
- UPC: 786725310203
- PPN: HBL-WA081004GSC
- UNSPSC: 39121324
CAD
$261.82
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
N4 Gasketed Screw-Cover 8X10X4 Carbon Steel - Gray
Features
- Bodies and covers fabricated from 14 gauge carbon steel
- Seams are continuously welded and ground smooth
- Cover contains closed cell oil resistant neoprene gasket
- Enclosure comes with stainless steel cover screws which thread into sealed wells to prevent liquid, dust, etc. from entering into the box through the screw holes
- Ground stud located in door
- No holes, knockout, or rear mounting holes
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Mexico
- Actual Height
- 4.250 in
- Color
- Ansi-61 Gray Textured
- Cubic Capacity
- 144 cu.in
- Finish
- Textured
- NEMA Rating
- 4
- Type
- Enclosure
- Weight
- 7.5 lb.
- Finish Type
- Textured
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- SC,BOX,GASKETED,MP,SW,8X10X4
- Harmonization Code
- 7326908688
- Lead Time
- 21 wk
- Order Multiple
- 1 EA
- Stock Indicator
- S - Shelf Stock
- UL Listed
- Yes
- Material
- Carbon Steel
- BOX SIZE
- 5.600x12.200x10.200 (in)
- Carton - Number of Sub Packs
- 1
- Carton - SCC-14 Next Lower Level Sub Pack
- 00786725310203
- Pallet Height
- 49.300 in
- Pallet Weight
- 752.520 lb.
- NAICS Code
- 3359326101
Actual Depth4.25 in
ApplicationDesigned for use as wiring box, junction box, pull box, and terminal box in many indoor or outdoor applications where dust or moisture is a problem.
Cover TypeScrew Cover
Depth4 in
Height4 in
StandardcULus
Width9 in
Engineering Drawing 3 Display TextMOD Center Drawings Instructions
Nema Rating4
Class CodeP01
Freight Class Code06316009
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
Sub Class CodeP01P006
ConstructionContinuously Welded Seams
Base Unit of MeasureEA
Carton - Gross Weight per Pack7.500 lb.
Carton - Pack DescriptionCarton
Carton - Total Units1 EA
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- Buy American Compliant
- Contact Manufacturer
- EU RoHS Indicator
- No
Certified ListedcULus
ListingsUL
