Burndy YAV26L4TC14FXG1 Non-Insulated Tin Plated Copper Terminal, 2/0 AWG, 1/4 Inch Stud, 4 Holes

MPN: YAV26L4TC14FXG1
UPC: 781810360538
PPN: BUR-10037860

$140.28

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Cu Hylug; 4 Holes; 2/0 (375/#24) DLO,125 Navy; 600V-35kV; 1/4" stud; Standard; Compression; 0.28 in BCD; Black

Documentation & Downloads

Specifications

Dimensions

Dimension - B Length fraction	13/16 in
Dimension - Bolt Hole Size inch	0.27 in
Dimension - F Width Center to Center inch	0.62 in
Dimension - Hole Size mm	7 mm
Dimension - Length Overall inch	3.07 in
Dimension - Outside Diameter inch	0.51 in
Dimension - Strip Length inch	1-1/16
Dimension - Z inch	0.83 in

Dimension - B Length inch	0.81 in
Dimension - Bolt Size fraction	1/4
Dimension - Hole Size inch	0.28 in
Dimension - L Length Overall mm	78 mm
Dimension - N inch	0.31 in
Dimension - Pad Width inch	1.38 in
Dimension - Stud Size inch	1/4
Physical Attribute - Tongue Angle	Straight

Certifications and Compliance

Certification - CSA Approved	No
Certification - UL Recognized	No
Standards - RoHS Compliance Status	CM

Certification - ETL	No
Certification - cULus	No
UL Listed	Yes

Conductor Related

Conductor - Copper DLO Size	2/0 (375/#24) DLO
Conductor - Copper Flex H Size	2/0 AWG
Conductor - Copper Flex K Size	2/0 AWG
Conductor - Copper Str Navy Size	125 (61) Navy
Conductor - CopperWeld Str Size	2/0 F AWG;2/0 G AWG;2/0 J AWG;2/0 K AWG;2/0 V AWG

Conductor - Copper Flex G Size	2/0 AWG
Conductor - Copper Flex I Size	2/0 AWG
Conductor - Copper Flex M Size	2/0 AWG
Conductor - Copper Str Size	2/0 AWG
Conductor - Material	Copper

General

Color Code	Black
Die Index	13
Feature - Barrel Type	Standard
Physical Attribute - Number of Holes	4
Plating Type	Tin
Type	Standard Barrel, Tin Plated
UPC 12 Digit	7818103605388
