Pass & Seymour PTTR62W PlugTail® Tamper-Resistant Receptacle 15A 125V White 0.866 Inch Depth
- MPN: PTTR62W
- UPC: 785007860276
- PPN: P-S-PTTR62W
- UNSPSC: 39121406
CAD
$44.41
/ EA
Available to Order from Manufacturer
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
PlugTail® Tamper-Resistant Receptacle 15A 125V White 0.866 Inch Depth
Features
- .036 inch thick, brass, triple-wipe power contacts for lasting retention.
- Extra heavy-duty 0.050'' thick brass mounting strap for superior performance and durability.
- No exposed terminals create a finger safe application before, during, and after installation.
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
- Crimped and welded contacts.
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
- Large brass contacts snugly terminate on device blade terminals.
- Pre-stripped connector leads fasten to conductors, easier than standard pigtails.
- Auto-ground clip assures positive ground.
- For covering patents, see www.legrand.us/patents.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Mexico |
|---|---|
| Height | 2.75 in |
| Color | White |
| Amperage | 15.0 A |
| Number of Poles | Double Pole |
| Phase | Three |
| Number of Wires | 3.0 |
| Wire Size | 14 - 10 AWG |
| Connection Location | Back Only |
| Operating Temperature Min | -40.0 °C |
| Warranty Type | 1-Year Limited Warranty |
| Wire Connection Type | PlugTail |
| Indoor/Outdoor | Indoor |
| Number of Receptacles | 2.0 |
| Depth | 0.866 in |
|---|---|
| Width | 1.625 in |
| Product Line | Pass & Seymour |
| Application Sector | Commercial |
| Is Tamper-Resistant | Yes |
| Special Features | Dual mechanical shutter system, plated steel wrap, built in connector, crimped & welded contacts |
| Standard | UL 498; FEDSPEC |
| Wall Plate Included | No |
| Outlet Type | Tamper-Resistant |
| Features | Brass Mounting Strap |
| Operating Temperature | -40°-60°C |
| NEMA Configuration Code | 5-15R |
| Operating Temperature Max | 60.0 °C |
| Voltage | 125.0 V |
