Hubbell Wiring Device-Kellems GFPST3C20M GFCI Linecord, 20A 120V AC, 3' Length, Manual Set, Black
- MPN: GFPST3C20M
- UPC: 783585703428
- PPN: HBL-GFPST3C20M
- UNSPSC: 39121406
CAD
$300.11
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Power Protection Products, GFCI Linecords, Commercial, Manual Set, 20A 120V AC, 5-20R, 3' Cord Length, 4-6 mA Trip Level, Black and Yellow
Features
- Unit must be reset by pushing the reset button upon plug in and after loss of primary power
- After a ground fault condition, unit must be reset by pushing the reset button
- Ideal for applications where operator injury might occur if equipment were to restart after a power failure
- Manual Set
Specifications
Key Specifications
- Country of Origin
- China
- Width
- 4.900 in
- Amperage Rating
- 20 A
- Color
- Black
- Standard
- UL Listed
- Type
- Line Cord
- Voltage Rating Description
- 120 VAC
- General Literature Asset 1 Display Text
- Portable GFCI Devices
- General Literature Asset 3 Display Text
- Entertainment Product Solution Guide
- Conductor Type
- Copper
- Number Of Conductors
- 3
- Strands
- Multi
- Class Code
- A40
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Replaced Catalog Number
- GFP3C20M
- Construction
- Fabricated
- Material - Insulation
- Elastomer
- Series
- Extra Heavy Duty
- BOX SIZE
- 10.700x13.000x9.700 (in)
- Carton - Number of Sub Packs
- 10
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783585703428
- Each - Pack Description
- Each
- NAICS Code
- 335931A107
Current / Amperage Rating20 A
Industry Standard(s)UL Listed
ApplicationLine Cord with Male/Female Ends
Special FeaturesManual Set
Temperature Rating-35 Degrees C to 66 Degrees C (-30 Degrees F to 150 Degrees F)
Voltage Rating120 VAC
Weight1.3 lb.
General Literature Asset 2 Display TextFood Processing Guide
Conductor Size#14 AWG
ConnectivityPlug-In
Outside Diameter0.3
StyleManual Set
Description - InvoiceGFCI LINECORD, 20A 120V, 3' MAN
Harmonization Code8536308000
MSDS FlagNo
Sub Class CodeA40A410
Current Rating20 A
Material - JacketPVC
Base Unit of MeasureEA
Carton - Gross Weight per Pack15.5 lb.
Carton - Pack DescriptionCarton
Carton - Total Units10 EA
Lowest Level UOMEach
