Telemecanique Sensors XMLK030P2D23 Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...30 PSI, 1/4NPT, 4...20 mA, M12, set of 1
- MPN: XMLK030P2D23
- PPN: TES-XMLK030P2D23
CAD
$149.22
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...30 PSI, 1/4NPT, 4...20 mA, M12, set of 1
Documentation & Downloads
Specifications
Key Specifications
- Pressure Sensor Type
- pressure transmitter
- Type Of Output Signal
- analogue
- Range Of Product
- Telemecanique Pressure sensors XM
- Pressure Sensor Size
- 30-30 psi
- Electrical Circuit Type
- control circuit
- Type Of Packing
- individual
- Local Display
- without
- Current Consumption
- < 20 mA
Analogue Output Function4...20 mA, 2-wire
Controlled Fluidair 0-80 °C) || fresh water 0-80 °C)
Electrical Connection1 male connector M12 4 pins
Quantity Per Setset of 1
Product Or Component Typeelectronic pressure sensors
[Us] Rated Supply Voltage24 V DC SELV 8-33 V)
Pressure Sensor NameXMLK
Fluid Connection Type1/4" - 18 NPT (male)
Complementary
- Accuracy
- 0.1 % of the measuring range
- [Uimp] Rated Impulse Withstand Voltage
- 0.5 kV
- Mechanical Durability
- 10000000 cycles
- Operating Position
- any position
- Electromagnetic Compatibility
- electrostatic discharge immunity test EN/IEC 61000-4-2 8 kV air, 6 kV contact || susceptibility to electromagnetic fields EN/IEC 61000-4-3 10 V/m 80...1000 MHz || electrical fast transient/burst immunity test EN/IEC 61000-4-4 2 kV || 1.2/50 µs shock waves immunity test EN/IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm || radiated RF fields EN/IEC 61000-4-6 10 V 0.15...80 MHz || immunity to magnetic fields EN/IEC 61000-4-8 30 A/m 50 Hz
- Drift Of The Sensitivity
- +/- 0.04 % of measuring range/°K
- Materials In Contact With Fluid
- nitrile (NBR) || stainless steel type AISI 303 || ceramic
- Destruction Pressure
- 90 psi
- Response Time On Output
- < 5 ms
Diameter36 mm
Repeat Accuracy+/- 1 % of the measuring range
Drift Of The Zero Point+/- 0.03 % of measuring range/°K
Measurement Accuracy+/- 1 % of the measuring range
Protection Typereverse polarity || load short-circuit
Maximum Permissible Accidental Pressure60 psi
Length65.5 mm
Net Weight0.11 kg
Pressure Setting Range0-30 psi
Offer Sustainability
- Rohs Exemption Information
- Yes
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Mercury FreeYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
Environment
- Product Certifications
- RCM || CSA C22.2 No 14 || EAC || UL 508
- Nema Degree Of Protection
- NEMA 4
- Standards
- EN/IEC 61326-2-3 || CE
- Vibration Resistance
- 20 gn 9-2000 Hz) EN/IEC 60068-2-6
- Ip Degree Of Protection
- IP65 EN/IEC 60529
Ambient Air Temperature For Operation0-80 °C
Ambient Air Temperature For Storage-25-80 °C
Shock Resistance25 gn 11 ms EN/IEC 60068-2-27
Protective TreatmentTC
