Telemecanique Sensors XMLK150P2D23 Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...150 PSI, 1/4NPT, 4...20 mA, M12, set of 1

MPN: XMLK150P2D23
PPN: TES-XMLK150P2D23
UNSPSC: 39122210

$149.22

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...150 PSI, 1/4NPT, 4...20 mA, M12, set of 1

Documentation & Downloads

Specifications

Key Specifications

Pressure Sensor Type	pressure transmitter
Range Of Product	Telemecanique Pressure sensors XM
Pressure Sensor Size	150-150 psi
Type Of Packing	individual
Pressure Sensor Name	XMLK
Fluid Connection Type	1/4" - 18 NPT (male)
Controlled Fluid	air 0-80 °C) \|\| fresh water 0-80 °C)
Electrical Circuit Type	control circuit

Type Of Output Signal	analogue
Electrical Connection	1 male connector M12 4 pins
Product Or Component Type	electronic pressure sensors
Local Display	without
Current Consumption	< 20 mA
Analogue Output Function	4...20 mA, 2-wire
Quantity Per Set	set of 1
[Us] Rated Supply Voltage	24 V DC SELV 8-33 V)

Complementary

Accuracy	0.1 % of the measuring range
[Uimp] Rated Impulse Withstand Voltage	0.5 kV
Drift Of The Zero Point	+/- 0.03 % of measuring range/°K
Materials In Contact With Fluid	stainless steel type AISI 303 \|\| ceramic \|\| nitrile (NBR)
Net Weight	0.11 kg
Mechanical Durability	10000000 cycles
Measurement Accuracy	+/- 1 % of the measuring range
Drift Of The Sensitivity	+/- 0.04 % of measuring range/°K
Destruction Pressure	450 psi
Pressure Setting Range	0-150 psi

Diameter	36 mm
Repeat Accuracy	+/- 1 % of the measuring range
Electromagnetic Compatibility	electrostatic discharge immunity test EN/IEC 61000-4-2 8 kV air, 6 kV contact \|\| susceptibility to electromagnetic fields EN/IEC 61000-4-3 10 V/m 80...1000 MHz \|\| electrical fast transient/burst immunity test EN/IEC 61000-4-4 2 kV \|\| 1.2/50 µs shock waves immunity test EN/IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm \|\| radiated RF fields EN/IEC 61000-4-6 10 V 0.15...80 MHz \|\| immunity to magnetic fields EN/IEC 61000-4-8 30 A/m 50 Hz
Length	65.5 mm
Scale Type	fixed differential
Operating Position	any position
Protection Type	reverse polarity \|\| load short-circuit
Maximum Permissible Accidental Pressure	300 psi
Response Time On Output	< 5 ms

Environment

Product Certifications	UL 508 \|\| EAC \|\| RCM \|\| CSA C22.2 No 14
Standards	CE \|\| EN/IEC 61326-2-3
Vibration Resistance	20 gn 9-2000 Hz) EN/IEC 60068-2-6
Nema Degree Of Protection	NEMA 4
Protective Treatment	TC

Ambient Air Temperature For Operation	0-80 °C
Shock Resistance	25 gn 11 ms EN/IEC 60068-2-27
Ip Degree Of Protection	IP65 EN/IEC 60529
Ambient Air Temperature For Storage	-25-80 °C
