Telemecanique Sensors XMLK300P2D23 Electronic pressure sensors, Pressure sensors XM, sensor XMLK, 0...300 PSI, 1/4NPT, 4...20 mA, M12, set of 1

MPN: XMLK300P2D23
PPN: TES-XMLK300P2D23
UNSPSC: 39122210

$149.22

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This product is part of the XM range, an offer of electronic pressure sensors. The electronic pressure sensor features a 1/4-18 NPT (male) for fluid connection. It is a pressure switch with a pressure setting range of 0psi to 300psi, a maximum permissible accidental pressure of 600psi and a destruction pressure of 900psi. It supports 4mA to 20mA, 2-wire analog output signal. It is furnished with 4-pin M12 male connector for electrical connection. It is an electronic pressure sensor with a rated supply voltage of 24V DC (voltage limits 8V to 33V) and a current consumption of <20mA. Its dimensions are 36mm (diameter) x 65.5mm (length). It weighs 0.11kg. It is suitable for monitoring air and fresh water. This product is certified by CSA C22.2 No 14, EAC, RCM and UL 508. It meets CE and EN/IEC 61326-2-3 standards. One of the most comprehensive catalogues of industrial and power pressure sensors on the market. The line of XM Pressure Sensors and Switches (formerly known as OsiSense) combine the latest pressure sensing technology with adaptability to virtually any configuration.

Documentation & Downloads

Specifications

Key Specifications

Pressure Sensor Type	pressure transmitter
Range Of Product	Telemecanique Pressure sensors XM
Pressure Sensor Size	300-300 psi
Type Of Packing	individual
Pressure Sensor Name	XMLK
Fluid Connection Type	1/4" - 18 NPT (male)
Controlled Fluid	air 0-80 °C) \|\| fresh water 0-80 °C)
Electrical Circuit Type	control circuit

Type Of Output Signal	analogue
Electrical Connection	1 male connector M12 4 pins
Product Or Component Type	electronic pressure sensors
Local Display	without
Current Consumption	< 20 mA
Analogue Output Function	4...20 mA, 2-wire
Quantity Per Set	set of 1
[Us] Rated Supply Voltage	24 V DC SELV 8-33 V)

Complementary

Accuracy	0.1 % of the measuring range
[Uimp] Rated Impulse Withstand Voltage	0.5 kV
Drift Of The Zero Point	+/- 0.03 % of measuring range/°K
Materials In Contact With Fluid	ceramic \|\| nitrile (NBR) \|\| stainless steel type AISI 303
Net Weight	0.11 kg
Mechanical Durability	10000000 cycles
Measurement Accuracy	+/- 1 % of the measuring range
Drift Of The Sensitivity	+/- 0.04 % of measuring range/°K
Destruction Pressure	900 psi
Pressure Setting Range	0-300 psi

Diameter	36 mm
Repeat Accuracy	+/- 1 % of the measuring range
Electromagnetic Compatibility	electrostatic discharge immunity test EN/IEC 61000-4-2 8 kV air, 6 kV contact \|\| susceptibility to electromagnetic fields EN/IEC 61000-4-3 10 V/m 80...1000 MHz \|\| electrical fast transient/burst immunity test EN/IEC 61000-4-4 2 kV \|\| 1.2/50 µs shock waves immunity test EN/IEC 61000-4-5 500 V 12 Ohm, 1 kV 42 Ohm \|\| radiated RF fields EN/IEC 61000-4-6 10 V 0.15...80 MHz \|\| immunity to magnetic fields EN/IEC 61000-4-8 30 A/m 50 Hz
Length	65.5 mm
Scale Type	fixed differential
Operating Position	any position
Protection Type	load short-circuit \|\| reverse polarity
Maximum Permissible Accidental Pressure	600 psi
Response Time On Output	< 5 ms

Environment

Product Certifications	UL 508 \|\| CSA C22.2 No 14 \|\| EAC \|\| RCM
Standards	CE \|\| EN/IEC 61326-2-3
Vibration Resistance	20 gn 9-2000 Hz) EN/IEC 60068-2-6
Nema Degree Of Protection	NEMA 4
Protective Treatment	TC

Ambient Air Temperature For Operation	0-80 °C
Shock Resistance	25 gn 11 ms EN/IEC 60068-2-27
Ip Degree Of Protection	IP65 EN/IEC 60529
Ambient Air Temperature For Storage	-25-80 °C
