Radiant RCD33W radiant® Two Single Pole/3-Way Switches, White
Radiant RCD33W radiant® Two Single Pole/3-Way Switches, White
- MPN: RCD33W
- UPC: 785007054972
- PPN: P-S-RCD33W
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$25.70/ EA
Description
Control two separate lights or devices from a single location with this combination switch. Both switches feature installation flexibility, usable for single-pole or 3-way applications. Designed to emulate the sleek lines of the collection's paddle switches, it delivers flexible, space-saving control with the sophisticated look of radiant.Made exclusively for use with screwless Wall Plates from the radiant® Collection, sold separately.
Features
- Offers installation flexibility with space-saving style, as part of the extensive offering from the radiant® Collection.
- Features durable, high-impact resistant thermoplastic construction.
- Designed to install easily with a narrower back body and captivated mounting screws.
- Patented Snap-In Light Module (sold separately) transforms a combination switch into an illuminated switch in seconds.
- More color options available to fit any style, including finishes to match current hardware and lighting trends.
- Complete the look with a sleek, screwless radiant® Wall Plate, and coordinate with other designer switches and outlets available from the radiant® Collection.
Specifications
Specifications
- Depth
- 1.59 in
- Height
- 3.81 in
- Finish
- Satin
- Material
- Thermoplastic
- Type
- Switch
- Load Type
- LED
- Amperage
- 15.0 A
- Voltage
- 120 VAC
- Load Type
- Halogen
- Switch Type
- Paddle
- Number of Gangs
- 1.0
- Indoor/Outdoor
- Indoor
- Number of Poles
- 3-Way
- Load Type
- Incandescent
- Number of Switches
- 1.0
- Throw Type
- Single Throw
- Features
- Decorator Style
- Requires Neutral Wire
- Yes
- Application Sector
- Residential
- Wire Connection Type
- Push Wire
- Connection Location
- Back and Side
- Wire Connection Type
- Wire Terminal
- Jigsaw Channel Availability
- Distribution
ColorWhite
Width1.29 in
Country of OriginChina
Product LinePass & Seymour
Load TypeCFL
StandardcULus
Load TypeXenon
Voltage125 VAC
StandardUL Listed
Load TypeUniversal
FeaturesCombination
Load TypeFluorescent
FeaturesLocator Light
Mounting TypeWall Box
Wall Plate IncludedNo
Compatible Add-OnsRCDLM
Operating Cycles50000.0
Number of PolesSingle Pole
Load Rating15 A @ 120/125 VAC
Environmental ConditionsUL94 V2
Special FeaturesThe radiant® collection is a step up from the standard with simple, classic options in wiring devices, home automation controls and screwless wall plates that complement today's homes. Unique "Up/Down" switches match the look and feel of radiant paddle switches.
Warranty Type1-Year Limited Warranty
Terminal Accommodation#14 AWG - #12 AWG
