Schneider Electric XB4BA941 Manual Overload Reset Push Button, 22mm, Red, IP66, 30-130mm Actuation

MPN: XB4BA941
PPN: SCH-XB4BA941

$39.63

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This manual overload reset with operating travel 14 mm and activating distance 30 to 130 push-button provides a complete button interface to your machines with a single panel cut-out It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 22mm diameter cut-outs and connected with simple screw-clamp connections High performance International standards & certifications ( Marine certification, IP66, Type 13 and 4X)
