Mersen

Mersen ST1000PVM SPD - Modular ST Series 1000V 50 kA 3-pole Microswitch Ind

SPD - Modular ST Series 1000V 50 kA 3-pole Microswitch Ind
  • MPN: ST1000PVM
  • UPC: 782001402112
  • PPN: FER-ST1000PVM

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$572.70/ EA

Description

Surge-Trap® Modular Surge Protective Device (SPD) is a no-fuse, fail-safe surge suppressor featuring Mersen’s patented TPMOV® technology inside. UL 1449 4th Edition approved, it is DIN-rail mountable featuring a fail-safe self-protected design, visual indicator, and a small footprint. A remote indicator option provides status to critical control circuitry. The Surge-Trap Modular SPD has a high short circuit rating and a thermally protected MOV, which eliminates the need for additional overcurrent protection devices.

Features

  • Easy installation or retrofit
  • DIN-rail mountable
  • Fail-safe, self-protected design
  • Remote indicator (optional)
  • Visual indicator
  • IP20 finger-safe design
  • Small footprint
  • No additional overcurrent protection devices required
  • 2-year warranty

Specifications

Specifications

Frequency Hz
50/60 Hz
Max Storage Temp
85 °C
Min Storage Temp
-40 °C
Torque Rating
15 lb-in
Nominal Operating Volt Rating Un
1000 V
Product Line
Surge-Trap® Modular SPDs DIN Rail
Wire Type
Solid / Stranded CU
Connection Terminal Type
Box
Number Of Poles
3-pole
Wire Connections
Box
Ul Spd Type
Type 1 Component Assembly
Ac Or Dc
DC
Nominal Discharge Current
20 kA
System Configuration
Photovoltaic
Max Operating Temp85 °C
Min Operating Temp-40 °C
Short Circuit Current Rating Sccr200 (most models) kA
Response Time<25 ns
Country Of OriginMX
Product BrandSurge-Trap®
Connection Terminal MaterialZinc-Plated Steel
Installation MountingDIN Rail
Wiring Range#6 to #14 AWG
Flammability RatingUL94 V0
Housing MaterialPET (Polyethelene Terphthalate)
Max Discharge Current Imax 8 2050 kA per phase
Number Of Wires3 Wire
