Tamper Resistant Decorator Duplex Receptacle, 20A 125V, 3-Wire Grounding, Ivory
Hubbell Wiring Device-Kellems

Hubbell Wiring Device-Kellems SNAP5362ITRA Tamper Resistant Decorator Duplex Receptacle, 20A 125V, 3-Wire Grounding, Ivory

  • MPN: SNAP5362ITRA
  • UPC: 783585552996
  • PPN: HBL-SNAP5362ITRA

CAD

$36.38

/ EA

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Company Stock:

0

Looking to buy a large quantity?

To view product inventory

Spec sheet

Description

Straight Blade Devices, Receptacles, Tamper Resistant, Decorator Duplex, SNAPConnect 2, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Ivory.

Features

  • Audible SNAP, indicates solid connection
  • Reduces installation time
  • Quick Connect- SNAPConnect, Tamper-Resistant, USA Product, Quick Connect- SNAPConnect, USA Product
  • Fully insulated design

Documentation & Downloads

Specifications

Key Specifications

Application
Extra Heavy Duty Specification Grade
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Item Type
Traditional Duplex
Material - Mounting Hardware
Screw Mounting
OEM Brand Name
Hubbell Wiring Device-Kellems
Series
Extra Heavy Duty
Type
Standard Duplex
Dimensions
3.28 in x 1.56 in x 1.1 in
Length
3.28 in
Amperage Rating
20 A
Current / Amperage Rating
20 A
Dielectric Strength
Withstands 2,000V minimum
Voltage Rating
125 V
Wattage
2500 W
Wire Size
#12 AWG
Carton Quantity
10 EA
ColorIvory Gray
Horsepower - Maximum1
MaterialNylon
Number Of Poles2-Pole
Operating TemperatureMaximum continuous 75°C and minimum -40°C without Impact
StyleSmooth Face Finder Groove Face
UPC783585552996
Display SizeStandard Sized Product
Width1.64 in
ConnectivityConnectorized
Current Rating20 A
PhaseSingle Phase
Voltage Rating Description125 V
Number Of Wires3-Wire
Nema Rating5-20R
