Hubbell Wiring Device-Kellems SNAP5362LATRA Tamper Resistant Decorator Duplex Receptacle 20A 125V 2-Pole 3-Wire Grounding Light Almond
- MPN: SNAP5362LATRA
- UPC: 783585553023
- PPN: HBL-SNAP5362LATRA
CAD
$36.38
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Straight Blade Devices, Receptacles, Tamper Resistant, Decorator Duplex, SNAPConnect 2, 20A 125V, 2-Pole 3- Wire Grounding, 5-20R, Light Almond.
Features
- Audible SNAP, indicates solid connection
- Quick Connect- SNAPConnect, Tamper-Resistant, USA Product
- Reduces installation time
- Fully insulated design
Documentation & Downloads
Specifications
Key Specifications
- Application
- Extra Heavy Duty Specification Grade
- Horsepower - Maximum
- 1
- Material
- Nylon
- Operating Temperature
- Maximum continuous 75°C and minimum -40°C without Impact
- Style
- Smooth Face
- UPC
- 783585553023
- Length
- 3.28 in
- Amperage Rating
- 20 A
- Current Rating
- 20 A
- Voltage Rating
- 125 V
- Number Of Wires
- 3-Wire
- Nema Rating
- 5-20R
ColorLight Almond
Item TypeTraditional Duplex
Number Of Poles2-Pole
SeriesExtra Heavy Duty
TypeStandard Duplex
Display SizeStandard Sized Product
Width1.64 in
Current / Amperage Rating20 A
Dielectric StrengthWithstands 2,000V minimum
Voltage Rating Description125 V
Wire Size#12 AWG
Carton Quantity10 EA
