Bryant RC308TR 15A Tamper Resistant Three Way Toggle Receptacle 120V AC, Side Wired
- MPN: RC308TR
- UPC: 883778302299
- PPN: HBL-RC308TR
- UNSPSC: 39122226
CAD
$41.83
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
One Three Way Toggle One Single Tamper Resistant Receptacle Combination Device, Residential 15A 120V AC, Self Grounding, Side Wired
Features
- Quiet snap action mechanism
- Self-grounding staple is standard
- Elongated strap with continuous plaster ears
- Tamper Resistant Receptacle
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
- Width
- 1.600 in
- Performance
- Environmental - Operating temperature - -20°C to 60°C
- Actuator
- Toggle
- Application
- Residential
- Contact Rating
- 15A
- Number of Poles
- 1) Three Way
- Operating Temperature
- Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
- Standard
- UL Listed
- Wattage
- 1800
- Connectivity
- Side Wired
- Number Of Poles
- 1) Three Way
- Freight Class Code
- 06168002
- Image Actual Or Representative
- A
- Material - Mounting Hardware
- Mounting Screws
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 2.75 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 10
- Each - Pack Description
- Each
Current / Amperage Rating15 A
Industry Standard(s)UL Listed
ActionSnap Switch
Amperage Rating15 A
Contact ConfigurationTwo Position
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Operating Cycles30,000 Minimum
Special FeaturesTamper Resistant Receptacle
Voltage Rating120 VAC
Voltage Rating Description120 VAC
Display SizeStandard Size
Description - InvoiceCOMBO, 15A 3-W & 15A125V RCPT TR, BN
Harmonization Code8536698000
MSDS FlagNo
Current Rating15 A
BOX SIZE4.300x9.100x2.600 (in)
Carton - Number of Sub Packs10
Carton - SCC-14 Next Lower Level Sub Pack883778302299
Case Weight60.000 lb.
Lowest Level UOMEach
Certifications
- EU RoHS Indicator
- Yes
