Square D B25.0 Thermal Fuse Holder, Class B, 200 Amp, 3 Pole, AIC 10,000 Amp
- MPN: B25.0
- UPC: 785901587552
- PPN: SCH-B25.0
CAD
$49.86
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
Linergy NEMA fuse holders are panel mount fuse holders that will accept class H, R, CC, M, and J fuses up to 200 Amps. This three pole fuse holder will accept class H fuses. The rating of the fuse can be up to 30 Amps with a 250 V maximum rating. The pressure wire connectors will accept 14 to 10 AWG (2.5 to 4 mm2) solid or stranded copper wire. Fuse clips are made of a copper alloy that is tin plated. The fuse clips are reinforced for a better connection. The fuse holder base is made of high impact thermoplastic. AIC Rating in accordance with UL512 is 10,000 Amp. This fuse holder is UL listed and CSA certified.
Features
- Operating on a reliable Class 20 trip curve, this thermal unit is designed to trip within 20 seconds or less under locked-rotor conditions ($600\%$ of full-load current). This timing provides the perfect operational balance for heavy industrial equipment, tolerating the normal high-inrush currents of high-inertia startups while intervening quickly enough to prevent catastrophic motor burnouts.
- Purpose-built for seamless physical integration, this plug-in heater element is fully compatible with standard Square D™ NEMA Size 1, M1, and M1P starters, along with Type B manual control units. The exact mechanical alignment ensures zero installation guesswork for field electricians, guaranteeing perfect low-resistance contact and making routine retrofitting or repairs remarkably fast.
Documentation & Downloads
Specifications
Additional
- Amperage
- 200A
- Number of Poles
- 3
- Thermal Overload Type
- melting alloy
- Fuse Types Accepted
- H, R, CC, M, J
- AIC Rating
- 10,000A
- Fuse Clip Material
- Tin plated copper alloy
- Base Material
- High impact thermoplastic
- China Rohs Regulation
- Out of China RoHS scope
- Eu Rohs Directive
- Out of EU RoHS scope
Maximum Voltage250V
Motor Tripping Class20
Range of ProductB
Maximum Fuse Amperage30A
Wire Connector Size14 to 10 AWG (2.5 to 4 mm2)
Fuse Clip FeatureReinforced connection
Pvc FreeYes
Reach RegulationContains SVHC above threshold
Country of OriginMexico
