Bryant RR15KW Tamper Resistant Duplex Receptacle, 15A 125V, 2-Pole 3-Wire Grounding, White
- MPN: RR15KW
- UPC: 883778100635
- PPN: HBL-RR15KW
- UNSPSC: 39121406
CAD
$1.83
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
TradeSelect, Straight Blade, Duplex Receptacle, Tamper Resistant, Cut Ears, 15A 125V, 2-Pole 3-Wire Grounding, 5-15R, White
Features
- Smooth indented face appearance
- Multiple-drive Slot/Phillips/Robertson head screws
- Tough thermoplastic ultrasonically welded cover and base
- Standard- Less Ears
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- United States
- Width
- 1.600 in
- SAP Material Group 3
- 008
- Application
- Residential Receptacles
- Environmental Conditions
- Indoor Dry Unless Protected By Additional Means
- Number of Poles
- 2-Pole
- Phase
- Single Phase
- Voltage Rating
- 125 VAC
- Wire Size
- #14 AWG to #12 AWG
- Connectivity
- Eight Push Wire Holes
- Nema Rating
- 5-15R
- Number Of Wires
- 3-Wire Grounding
- Image Actual Or Representative
- A
- Replacement Catalog Number
- RR15W
- Current Rating
- 15 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 11.7 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 100
- Lowest Level UOM
- Each
Current / Amperage Rating15 A
PerformanceEnvironmental - Operating temperature - -20°C to 60°C;Mechanical - Terminal - Terminal screws accepts up to #12 AWG, Push wire designed for #14 AWG solid copper wire only
Amperage Rating15 A
ColorWhite
NEMA Rating5-15R
Number of Wires3-Wire Grounding
Special FeaturesStandard- Less Ears
Wattage1875
Voltage Rating Description125 VAC
Display SizeStandard Sized Product
Number Of Poles2-Pole
Description - InvoiceRESI DUP RCPT, 15A 125, LESS EARS, WH
MSDS FlagNo
Material - Mounting HardwareScrew Mounting
MaterialThermoplastic
BOX SIZE4.100x16.400x10.300 (in)
Carton - Number of Sub Packs100
Carton - SCC-14 Next Lower Level Sub Pack883778100635
Each - Pack DescriptionEach
Certifications
- EU RoHS Indicator
- Yes
