Woodhead 945-3-86 Standard Duty Cord Reel, 10.67m (35.0') Cord Length, 16/3 SJTOW, 13W Fluorescent Lamp
- MPN: 945-3-86
- PPN: WOD-945-3-86
CAD
$2013.38
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Standard Duty Cord Reel, 10.67m (35.0') Cord Length, 16/3 SJTOW, 13W Fluorescent Lamp
Documentation & Downloads
Specifications
Material Info
| Engineering Number | 945-3-86 |
|---|
Agency Certification
| UL | E22769 |
|---|
Electrical
| Lamp Type | Fluorescent |
|---|---|
| Current - Maximum per Contact | 6.0A |
| Lamp Wattage - Maximum | 13W |
| GFCI | No |
| Cord Type | 16/3 SJTOW |
|---|---|
| Voltage - Maximum | 120V |
| Bulb Included | Yes |
| On/Off Switch | Yes |
Physical
| Mounting Style | Swinging |
|---|---|
| Material - Housing | Steel |
| Number of Conductors | 3 |
| Cable Movement | Ratchet Lock |
| Drum Lock | Ratchet |
| Material - Coating | Powder Coating |
| Cord Length | 10.67m (35.0') |
|---|---|
| Packaging Type | Carton |
| Wire Size AWG | 16 |
| Retraction Weight | 0.9kg (2.0 lb) |
| Primary Cord/Cable Entry | N/A |
General
| Product Family | Electric Reels |
|---|---|
| Type | Cord Reel |
| Series | 130090 |
| Enclosure Rating | NEMA 1 |
| Product Name | Super-Safeway™ |
| Width | 13.06mm (5.160") |
| NEMA Configuration | NEMA 5-15 |
| Depth | 0.24m (9.59") |
| Cable Length | 0.457m (1.50') |
|---|---|
| Comments | Ratchet Lock (ON/OFF Switchable) |
| UPC | 78678827906 |
| Height | 0.32 (12.62") |
| Product Literature Order No | 987650-8061 |
| Overview | Electric Reels |
| Duty | Standard |
