Killark ZS103CR 1/2 Inch Nylon Cord Connector, Cord Range .187-.250 Inch, Red
- MPN: ZS103CR
- UPC: 783936989655
- PPN: HBL-ZS103CR
- UNSPSC: 39121431
CAD
$14.11
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
1/2" Nylon Cord Connector, Cord Range .187-.250, Red
Features
- Nylon retention ring for increased holding power
- Neoprene bushing seals against moisture
- Nylon connectors obtain approximately the same retention values as metal cord connectors
- Nylon retention ring for increased holding power. Neoprene bushing seals against moisture. Nylon connectors obtain approximately the same cord retention values with hand tightening that can be produced only by wrench tightening of metal cord connectors.
Specifications
Key Specifications
- Country of Origin
- China
- Height
- 2 in
- Length
- 2 in
- Color
- Gray
- Size
- 2 in x 1 in x 2 in
- Type
- Straight Cord Connector
- Width
- 1 in
- Frequency Rating
- 60 Hz
- ARRA Compliant
- Contact Manufacturer
- Description - Invoice
- CONN STR 1/2" .187-.250 NM
- Harmonization Code
- 3926909989
- Lead Time
- 20 wk
- Order Multiple
- 1 EA
- Sub Class Code
- D30D234
- Cord Range
- .187-.250,
- Gross Weight with Packaging
- 0.07
- Color Code
- Red
- Series
- Z Series
- BOX SIZE
- 5.000x8.250x5.500 (in)
- Carton - Number of Sub Packs
- 25
- Carton - SCC-14 Next Lower Level Sub Pack
- 00783936989655
- Master Pack Description
- Each
Dimensions2 in x 1 in x 2 in
Hub Size1/2"
ApplicationDurable nylon construction makes these connectors perfectly suited to corrosive environments. Typical applications for nylon cord connectors include food processing facilities, chemical and sewage treatment plants, and off-shore and dockside installations
FinishNatural
Special FeaturesNylon retention ring for increased holding power. Neoprene bushing seals against moisture. Nylon connectors obtain approximately the same cord retention values with hand tightening that can be produced only by wrench tightening of metal cord connectors.
Weight0.07 lb.
Finish TypeNatural
Power Factor0.9
Class CodeD30
Freight Class Code06168002
Image Actual Or RepresentativeR
MSDS FlagNo
Returnable IndicatorYes
Cable Range.187 - .250 in
CSA File NumberLR73478
UL File NumberE22698
MaterialNylon
Base Unit of MeasureEA
Carton - Gross Weight per Pack1.750 lb.
Carton - Pack DescriptionCarton
Carton - Total Units25 EA
NAICS Code3359323102
