Leviton 4586-CWP 15 Amp 250 Volt NEMA L6-15P Power Inlet Receptacle, Locking Blade, Nylon Strap
- MPN: 4586-CWP
- UPC: 078477046197
- PPN: LEV-4586-CWP
CAD
$140.64
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
15 Amp, 250 Volt, NEMA L6-15P, 2P, 3W, Power Inlet Receptacle, Locking Blade, Industrial Grade, Self-Grounding, Standard Wire Wells Wired, Nylon Strap - GRAY
Features
- Leviton’s industry leading locking devices, such as our Black & White line of industrial grade plugs and connectors and our V-0-Max line of industrial grade flush receptacles, offer superior performance, long lasting reliability and other features that are backed by a lifetime warranty.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | United States |
|---|
| RoHS Compliant | True |
|---|
Standards and Certifications
| ANSI | C-73 |
|---|---|
| NEMA | WD-6 |
| Warranty | 10-Year Limited |
| CSA C22.2 No. 42 | File LR-16347 |
|---|---|
| UL498 | File E13393 |
Material Specifications
| Body Material | Nylon |
|---|---|
| Cover and Plate Material | Glass-Filled Thermoplastic |
| Grounding Screw | Brass 8-32 |
| Strap Material | Nylon |
| Color | Gray |
|---|---|
| Face Material | Nylon |
| Line Contacts | Brass |
| Terminal Screws | Brass 10-32 |
Mechanical Specifications
| Product ID | Ratings and NEMA I.D. permanently marked on device |
|---|---|
| Terminal Accom. | 18-10 AWG |
| Termination | Standard Wire Wells |
| Screw Terminal Torque | 10-14 in-lbs |
|---|---|
| Terminal ID | Brass-Hot, Green-Ground, Silver-Neutral |
Environmental Specifications
| Flammability | Rated V-2 per UL 94 |
|---|
| Operating Temperature | -40°C to 60°C |
|---|
Electrical Specifications
| Amperage | 15 A |
|---|---|
| Dielectric Voltage | Withstands 1500V per UL498 |
| Pole | 2 |
| Voltage | 250 VAC |
| Current Limiting | Full Rated Current |
|---|---|
| Grounding | Self Grounding |
| Temperature Rise | Max 30C after 250 cycles OL at 200 percent rated current |
| Wire | 3 |
AC Horsepower Ratings
| At Rated Voltage | 1-1/2 HP |
|---|
