Pass & Seymour PTTR8200PILA 15A Hospital-Grade Receptacle, Power Indicating, Light Almond, 0.866 Inch Depth
Pass & Seymour PTTR8200PILA 15A Hospital-Grade Receptacle, Power Indicating, Light Almond, 0.866 Inch Depth
- MPN: PTTR8200PILA
- UPC: 785007041330
- PPN: P-S-PTTR8200PILA
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$49.28/ EA
Description
Built for the harshest medical environments, Pass and Seymour power indicating receptacles feature two industry-exclusive green LEDs that offer clear visual assurance of power indication at the receptacleeven with critical equipment plugged into the device. The LEDs operate independently from one another to accommodate split-circuit wiring installations. Tamper-resistant protection comes standard with each receptacle to further enhance safety. For detailed PlugTail® information, visit our PlugTail® Headquarters.
Features
- .036 inch thick, brass, triple-wipe power contacts for lasting retention.
- Plated steel wrap strap design for maximum durability and corrosion resistance.
- No exposed terminals create a finger safe application before, during, and after installation.
- Built-in connector features large brass terminal blades to ensure consistent, reliable electrical connections.
- Crimped and welded contacts.
- Ultrasonically welded polycarbonate connector housing secures terminations and conductors in a UL Listed, finger safe housing.
- Large brass contacts snugly terminate on device blade terminals.
- Pre-stripped connector leads fasten to conductors, easier than standard pigtails.
- Auto-ground clip assures positive ground.
- For covering patents, see www.legrand.us/patents.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
- Wire Size: #12 AWG THHN
Specifications
Specifications
- Depth
- 0.866 in
- Color
- Light Almond
- Product Line
- Pass & Seymour
- Country of Origin
- Mexico
- Standard
- FSUL
- Amperage
- 15.0 A
- Standard
- FEDSPEC
- Standard
- UL Listed
- Standard
- CSA Listed
- Wall Plate Included
- No
- Number of Receptacles
- 2.0
- Number of Poles
- Double Pole
- Application Sector
- Healthcare
- NEMA Configuration Code
- 5-15R
- Environmental Conditions
- UL94 V2
- Operating Temperature Max
- 60.0 °C
- Operating Temperature
- -40°-60°C
- Features
- Single Piece Plated Steel Mounting Strap
Height2.75 in
Width1.625 in
Special FeaturesBuilt for the harshest medical environments, Pass&Seymour PlugTail power indicating receptacles feature two industry-exclusive green LEDs that offer clear visual assurance of power indication at the receptacle—even with critical equipment plugged into the device. The LEDs operate independently from one another to accommodate split-circuit wiring installations. Tamper-resistant protection comes standard with each receptacle to further enhance safety.
PhaseSingle
StandardcULus
Voltage125.0 V
Wire Size12 AWG
Number of Wires3.0
Indoor/OutdoorIndoor
Is Tamper-ResistantYes
Outlet TypeHospital Grade
Outlet TypeTamper-Resistant
Connection LocationBack Only
Wire Connection TypePlugTail
Warranty Type1-Year Limited Warranty
Operating Temperature Min-40.0 °C
Dielectric StrengthWithstands 2000V minimum
