Mersen 1MSC103 1MSC Semiconductor Fuse Block, Phenolic Body, 600 VAC, 200 kA SCCR
- MPN: 1MSC103
- UPC: 782001272777
- PPN: FER-1MSC103
CAD
$313.50
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Mersen 1SC and 1MSC semiconductor fuse blocks feature modular mounting that offers greater flexibility in adjusting to various fuse lengths. Both stud type and integral box connector versions are offered to allow for user preference of wire terminations. The integral box connector versions also provide for greater heat dissipation. All modular blocks are supplied in pairs but need to be ordered as two items to suit one fuse. Mounting hardware is supplied with the blocks
Features
- Accommodates a large range of semiconductor fuses
- Heat dissipating integral box connector versions
- Compact footprint
- Modular two-piece design
- Stud versions
- Rugged phenolic insulators
Specifications
Product Details
- Body Material
- Phenolic
- ROHS Compliant
- Consult Technical Services
- SCCR
- 200 kA
- Wiring Range
- Al/Cu (2) 250kcmil - #6 AWG, Al/Cu 2/0 - #6 AWG
- DC Voltage
- 600 VDC
- Number of Poles
- 1
- Mounting
- Screw Mount
StandardsUL Recognized Component to standard 4248-1, File E171957
UL CertificationE171957 IZLT2.E171957
Materials ContactAluminum
AC Voltage600 VAC
CE conformityConsult Technical Services
Lead FreeConsult Technical Services
Connection Terminal TypeBox
