Mersen 1MSC108 Modular Semiconductor Fuse Block, 600 VAC, 200 kA, Aluminum, Phenolic
- MPN: 1MSC108
- UPC: 782001331269
- PPN: FER-1MSC108
CAD
$1113.28
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Mersen 1SC and 1MSC semiconductor fuse blocks feature modular mounting that offers greater flexibility in adjusting to various fuse lengths. Both stud type and integral box connector versions are offered to allow for user preference of wire terminations. The integral box connector versions also provide for greater heat dissipation. All modular blocks are supplied in pairs but need to be ordered as two items to suit one fuse. Mounting hardware is supplied with the blocks
Features
- Compact footprint
- Accommodates a large range of semiconductor fuses
- Stud versions
- Modular two-piece design
- Rugged phenolic insulators
- Heat dissipating integral box connector versions
Specifications
Product Details
- SCCR
- 200 kA
- Materials Contact
- Aluminum
- DC Voltage
- 600 VDC
- Lead Free
- Consult Technical Services
- CE conformity
- Consult Technical Services
- Connection Terminal Type
- Box
- Wiring Range
- Al/Cu (2) 250kcmil - #6 AWG, Al/Cu 2/0 - #6 AWG
ROHS CompliantConsult Technical Services
AC Voltage600 VAC
StandardsUL Recognized Component to standard 4248-1, File E171957
Body MaterialPhenolic
MountingScrew Mount
UL CertificationE171957 IZLT2.E171957
Number of Poles1
